YOKOGAWA UT350-01 Instruction Manual

6-8
<Toc> <6. Function Block Diagram and Descriptions>
IM 05D01D02-41E 1st Edition : May 31,2000-00
■ Retransmission Output
PV, target setpoint, or control output can be output to retransmission output (OUTPUT2/
RET).
Each function can be set by the following parameters.
Setup Parameters
Function Parameter
Retransmission output type RET
Retransmission output scale RTH, RTL
FUNC
FUNC
Menu
■ 15 V DC Loop Power Supply
The 15 V DC loop power supply (OUTPUT2/RET) uses the same terminal as retransmis-
sion output. The 15 V DC loop power supply can not be used when retransmission output is
used. To use the 15 V DC loop power supply, set “4” in retransmission output type selection
parameter RET.
Each function can be set by the following parameters.
Setup Parameters
Function Parameter
Retransmission output type RET FUNC
Menu
