1.Set to radio transmission flash mode.
Short press the [ ]button until the screen
displays that the flash mode is set to radio
mode [ ].
2.Set the wireless channel
Short press the [CH/ID] button, then press
[+] or [-] button to set the channel (1-16),
and press [SET/FN] button to confirm.
5.Master unit setting
T h e m o d e , b r i g h t n e s s , e x p o s u r e
compensation and other parameters of the
flash are set in the master unit.
3.Set the wireless ID
Long press the [CH/ID] button to set the ID
(0000-9999) .Then short press [SET/FN] and
[+][-] button in turn. Set the master unit and
slave unit to the same ID. If the master unit
does not have ID setting, please set the ID of
YN200 to the default 0000.
4.Set up the grouping
Press the [GR] button to set the slave
grouping (A/B/C/D/E/F).
Wireless Flash Shooting: Radio Transmission
-7-
