271846-YTG-B-0208
12 Johnson Controls Unitary Products
TABLE 9: COOLING PERFORMANCE DATA - CU 5-20 TON VERTICAL MODELS
CU060
5 TON
2000 CFM
9 GPM
15 GPM
EWT
EWT
65°F 85°F
105°F 65°F 85°F
105°F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62°F
75°F 62.1 48.9 2.87 58.3 47.2 3.65 54.4 45.4 4.67 63.1 49.4 2.71 59.2 47.5 3.45 55.3 45.7 4.41
80°F 62.1 58.2 2.87 58.3 57.0 3.65 54.4 54.1 4.67 63.1 58.7 2.71 59.2 56.7 3.45 55.3 54.6 4.41
85°F 65.4 65.4 2.91 61.5 61.5 3.71 57.8 57.8 4.74 66.3 66.3 2.74 62.5 62.5 3.53 58.8 58.8 4.45
67°F
75°F 66.4 38.1 2.93 62.0 36.9 3.71 57.2 34.9 4.70 67.6 39.3 2.75 63.3 37.5 3.49 58.4 35.4 4.43
80°F 66.4 48.0 2.93 62.0 46.2 3.71 57.2 44.3 4.70 67.6 48.5 2.75 63.3 46.7 3.49 58.4 44.8 4.43
85°F 66.4 57.8 2.93 62.0 55.7 3.71 57.2 53.7 4.70 67.6 58.4 2.75 63.3 56.3 3.49 58.4 54.2 4.43
72°F
75°F 71.4 28.7 2.99 66.6 27.4 3.77 61.4 25.5 4.77 72.7 29.1 2.79 68.0 28.0 3.53 63.0 26.1 4.47
80°F 71.4 38.1 2.99 66.6 36.2 3.77 61.4 34.3 4.77 72.7 38.6 2.79 68.0 36.8 3.53 63.0 34.9 4.47
85°F 71.4 47.3 2.99 66.6 45.6 3.77 61.4 43.7 4.77 72.7 47.8 2.79 68.0 46.1 3.53 63.0 44.2 4.47
CU096
8 TON
3200 CFM
15 GPM
24 GPM
EWT
EWT
65°F 85°F
105°F 65°F 85°F
105°F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62°F
75°F 99.0 78.9 4.44 93.9 76.4 5.65 87.2 73.4 7.22 100.3 79.3 4.21 94.9 76.8 5.38 88.5 74.0 6.87
80°F 99.0 93.9 4.44 93.9 91.5 5.65 87.2 87.2 7.22 100.3 94.7 4.21 94.9 92.0 5.38 88.5 88.3 6.87
85°F 104.2 104.2 4.50 98.8 98.8 5.71 92.4 92.4 7.32 105.4 105.4 4.25 100.0 100.0 5.44 93.8 93.8 6.91
67°F
75°F 105.9 62.3 4.47 99.1 59.4 5.69 91.4 56.2 7.26 107.3 62.9 4.24 100.6 60.1 5.41 93.1 56.9 6.88
80°F 105.9 77.5 4.47 99.1 74.6 5.69 91.4 71.5 7.26 107.3 78.0 4.24 100.6 75.2 5.41 93.1 72.2 6.88
85°F 105.9 93.2 4.47 99.1 90.2 5.69 91.4 86.8 7.26 107.3 93.8 4.24 100.6 91.0 5.41 93.1 87.8 6.88
72°F
75°F 113.6 45.7 4.54 106.5 43.9 5.76 98.3 40.9 7.33 115.3 46.4 4.28 108.2 44.7 5.43 100.4 41.8 6.93
80°F 113.6 61.2 4.54 106.5 58.4 5.76 98.3 55.3 7.33 115.3 61.8 4.28 108.2 59.1 5.43 100.4 56.2 6.93
85°F 113.6 76.3 4.54 106.5 73.6 5.76 98.3 70.6 7.33 115.3 76.9 4.28 108.2 74.3 5.43 100.4 71.5 6.93
CU120
10 TON
4000 CFM
18 GPM
30 GPM
EWT
EWT
65°F 85°F
105°F 65°F 85°F
105°F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62°F
75°F 125.4 99.6 5.76 118.8 96.6 7.32 109.7 92.5 9.35 127.3 100.6 5.43 120.4 97.3 6.93 111.7 93.5 8.83
80°F 125.4 118.6 5.76 118.8 115.4 7.32 109.7 109.7 9.35 127.3 119.6 5.43 120.4 116.7 6.93 111.7 111.4 8.83
85°F 132.4 132.4 5.86 125.2 125.2 7.52 117.0 117.0 9.48 134.2 134.2 5.47 127.1 127.1 7.07 119.1 119.1 8.86
67°F
75°F 134.2 78.9 5.86 125.7 75.3 7.43 115.8 71.2 9.41 136.5 79.9 5.50 127.8 76.1 6.98 118.0 72.1 8.87
80°F 134.2 98.0 5.86 125.7 94.4 7.43 115.8 90.5 9.41 136.5 98.9 5.50 127.8 95.4 6.98 118.0 91.3 8.87
85°F 134.2 117.7 5.86 125.7 114.0 7.43 115.8 109.7 9.41 136.5 118.8 5.50 127.8 114.8 6.98 118.0 110.6 8.87
72°F
75°F 144.4 58.1 5.98 134.4 55.7 7.55 124.4 52.0 9.55 147.0 58.8 5.53 137.5 55.6 7.08 127.3 53.0 8.96
80°F 144.4 77.6 5.98 134.4 73.8 7.55 124.4 69.9 9.55 147.0 78.5 5.53 137.5 75.0 7.08 127.3 71.1 8.96
85°F 144.4 96.6 5.98 134.4 93.0 7.55 124.4 89.3 9.55 147.0 97.9 5.53 137.5 94.1 7.08 127.3 90.4 8.96
CU180
15 TON
6000 CFM
27 GPM
45 GPM
EWT
EWT
65°F 85°F
105°F 65°F 85°F
105°F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62°F
75°F 185.2 146.0 9.14 175.0 141.3 11.25 163.0 136.1 14.03 187.5 147.0 8.65 177.4 142.3 10.64 165.9 137.2 13.21
80°F 185.2 173.9 9.14 175.0 169.7 11.25 163.0 162.4 14.03 187.5 175.3 8.65 177.4 170.2 10.64 165.9 164.0 13.21
85°F 194.6 194.6 9.41 184.8 184.8 11.54 172.8 172.8 14.28 197.8 197.8 8.90 187.8 187.8 10.94 176.4 176.4 13.34
67°F
75°F 197.2 115.5 9.37 185.0 110.4 11.44 171.2 104.5 14.24 200.6 116.8 8.87 188.6 111.8 10.80 175.2 106.3 13.38
80°F 197.2 143.0 9.37 185.0 138.1 11.44 171.2 132.6 14.24 200.6 144.3 8.87 188.6 139.7 10.80 175.2 134.3 13.38/
85°F 197.2 172.2 9.37 185.0 166.8 11.44 171.2 161.0 14.24 200.6 173.9 8.87 188.6 168.5 10.80 175.2 162.7 13.38
72°F
75°F 211.5 86.3 9.66 198.2 81.1 11.75 183.5 75.4 14.56 215.4 88.1 9.11 202.4 82.8 11.03 188.0 77.3 13.63
80°F 211.5 109.5 9.66 198.2 104.4 11.75 183.5 98.8 14.56 215.4 111.1 9.11 202.4 105.9 11.03 188.0 100.4 13.63
85°F 211.5 134.1 9.66 198.2 129.1 11.75 183.5 123.6 14.56 215.4 135.6 9.11 202.4 130.6 11.03 188.0 125.4 13.63
CU240
20 TON
8000 CFM
36 GPM
60 GPM
EWT
EWT
65°F 85°F
105°F 65°F 85°F
105°F
EWB EDB TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW TC SC kW
62°F
75°F 250.6 192.3 12.57 237.2 189.8 15.22 219.6 185.1 18.63 253.9 193.7 12.07 240.2 191.2 14.56 223.8 186.8 17.71
80°F 250.6 228.4 12.57 237.2 226.6 15.22 219.6 222.4 18.63 253.9 229.8 12.07 240.2 227.8 14.56 223.8 224.1 17.71
85°F 264.7 264.7 12.70 252.8 252.8 15.27 239.6 239.6 18.86 266.9 266.9 12.85 255.0 255.0 14.66 242.7 242.7 17.98
67°F
75°F 266.9 150.4 12.97 252.7 147.5 15.53 235.0 143.4 19.00 269.9 151.7 12.41 256.7 149.3 14.84 239.2 144.7 18.12
80°F 266.9 185.7 12.97 252.7 183.5 15.53 235.0 180.1 19.00 269.9 186.9 12.41 256.7 185.4 14.87 239.2 181.2 18.12
85°F 266.9 221.0 12.97 252.7 219.5 15.53 235.0 216.9 19.00 269.9 222.3 12.45 256.7 221.3 14.87 239.2 217.8 18.12
72°F
75°F 283.5 109.5 13.45 268.6 106.4 16.04 250.2 101.8 19.46 287.3 111.3 12.83 273.4 108.1 15.25 255.5 103.6 18.44
80°F 283.5 143.9 13.45 268.6 141.7 16.04 250.2 138.1 19.46 287.3 146.5 12.83 273.4 143.6 15.25 255.5 139.7 18.44
85°F 283.5 178.3 13.45 268.6 177.0 16.04 250.2 174.2 19.46 287.3 181.7 12.83 273.4 179.1 15.25 255.5 176.0 18.44
