York CH060 - General Data: Horizontal CH Models; Performance Metrics; Component Specifications; Weight and Notes

271846-YTG-B-0208
Johnson Controls Unitary Products
5
NOTE: Cooling performance is rated at 80°F dry bulb 67°F wet bulb entering air temperature, CFM listed, 85°F entering
95°F leaving water temperature, and water flow rate listed. Gross capacity does not include the effect of evapora-
tor fan motor heat.
TABLE 1: GENERAL DATA - CH060-120 5-10 TON HORIZONTAL MODELS
Model - CH CH060 CH096 CH120
Nominal Cooling(Ton) 5 8 10
Cooling Performance
Gross Cooling Capacity(Btuh) 64100 101800 126000
Design CFM 2000 3200 4000
EER 13.3 13.4 12.0
Compressor-Type Scroll
Number Used 1 2 2
Evaporator Coil-Type Copper Tubes, Aluminum Fins
Face Area(sq ft) 5.28 9.17 9.17
Rows/FPI 3/13 3/13 3/13
Condenser-Type Coaxial
Number Used/Tons Capacity 1/5 2/4 2/5
Nominal Water flow rate (gpm) 15 24 30
Condenser Water Connections 1" FPT 1-1/4" FPT 1-1/4" FPT
Evaporator Fan-Type Centrifugal, Forward Curved
Number Used 1 2 2
Diameter x Width (in) 10x10 10x8 10x8
Drive Adjustable Belt
Motor HP (Standard/Oversize) 1/NA 1.5/2 2/3
Filters
Number Used-Size(in) 2-20x20x2 2-20x25x2
1-20x20x2
2-20x25x2
1-20x20x2
Condensate Drain Connection 3/4FPT
Weight 460 710 760
