167791-BIM-B-0606
30 Unitary Products Group
TABLE 29: DL PHYSICAL DATA
Component
Models
-06 -07 -08 -10 -12
Evaporator
Blower
Blower, Centrifugal (Dia X Wd. In) 15 x 15 12 x 12 12 X 12 15 x 15 15 x 15
Motor, Standard (HP) 1-1/2 2 3 2 3
Motor, Optional (HP) 2 3 3 3 5
Evaporator
Coil
Rows 2 2 3 2 3
Fins per Inch 15 15 15 15 15
Height (in.) 30 32 32 40 40
Face Area (ft2) 9.9 10.67 10.67 13.2 13.2
Condenser
Fan
(2 per Unit)
Propeller Dia. (in.) 24 24 24 24 24
Motor (HP each) 1/3 3/4 3/4 3/4 3/4
CFM, Nominal (each) 3400 4400 4400 4400 4400
Condenser
Coil
(2 per unit)
Rows 1 1 1 1 2
Fins per Inch 20 20 20 20 20
Height (in.) 24 28 36 44 44
Face Area (ft2) 7.9 9.33 12 14.5 14.5
Refrigerant
Charge
System 1 (lb/oz) 4/6 4/10 5/8 6/12 10/12
System 2 (lb/oz) 4/0 3/14 5/2 6/12 11/0
Compressors
Quantity 2 2 2 2 2
Type Recip Recip Recip. Recip Scroll
Air Filters
Size (Wd. X Ht. x Thickness in.) 25x20x2 25x16x2 25x16x2 25x20x2 25x20x2
Number Per Unit 4 4 4 4 4
TABLE 30: DU PHYSICAL DATA
Component
Models
-06 -07 -08 -10 -12
Evaporator
Blower
Blower, Centrifugal (Dia. X Wd.
in.)
12 x 12 12 x 12 12 X 12 15 x 15 15 x 15
Motor, Standard (HP)
1-1/2 2 3 2 3
Motor, Optional (HP)
2 33 3 5
Evaporator
Coil
Rows
3 33 4 4
Fins per Inch
15 15 15 15 15
Height (in.)
32 32 32 40 40
Face Area (ft.
2
each)
10.67 10.67 10.67 13.2 13.2
Condenser
Fan
(2 per Unit)
Propeller Dia.
(in., each)
24 24 24 24 24
Motor (HP, each)
1/3 1/3 1/3 3/4 3/4
CFM, Nominal (each)
3400 3400 3400 4400 4400
Condenser
Coil
(2 per unit)
Rows (each)
Sys 1: 2 Row
22 2 2
Sys 2: 1 Row
Fins per Inch
20 20 20 20 20
Height (in., each)
36 36 36 44 44
Face Area (ft.
2
each)
12 12 12 14.5 14.5
Refrigerant
Charge
System 1 (lb./oz.)
8/0 8/12 9/8 12/0 9/14
System 2 (lb./oz.)
4/12 9/0 8/2 11/0 9/4
Compressors
Quantity
2 22 2 2
Type
Recip. Recip Recip. Recip Scroll
Air Filters
Size (Wd. x Ht. x Thickness in.)
25x16x2 25x16x2 25x16x2 25x20x2 25x20x2
