York DNH024 - Superheat Charging Table for D1 Nh024; Superheat Charging Table for D1 Nh030; Superheat Charging Table for D1 Nh036

66324-YIM-B-1004
Unitary Products Group 21
TABLE 13: SUPERHEAT CHARGING TABLE FOR D1NH024
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 800 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 29.2 29.5 29.7 30.0 30.2 30.5 30.7 31.5 32.2 33.0 33.8
70 25.1 25.8 26.4 27.0 27.7 28.3 29.0 29.8 30.7 31.6 32.5
75 21.0 22.0 23.1 24.1 25.1 26.2 27.2 28.2 29.2 30.2 31.2
80 16.9 18.3 19.7 21.2 22.6 24.0 25.5 26.5 27.6 28.7 29.8
85 12.8 14.6 16.4 18.2 20.1 21.9 23.7 24.9 26.1 27.3 28.5
90 5.7 8.0 10.4 12.7 15.1 17.4 19.8 21.8 23.8 25.7 27.7
95 - - - 7.3 10.1 13.0 15.9 18.7 21.4 24.2 26.9
100 - - - 5.6 7.7 9.9 12.0 15.2 18.4 21.6 24.8
105 ----5.46.88.211.815.419.122.7
110 -------8.412.416.520.6
115 --------9.414.018.5
TABLE 14: SUPERHEAT CHARGING TABLE FOR D1NH030
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 1,000 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 23.8 25.6 27.5 29.3 31.1 32.9 34.7 35.3 35.9 36.5 37.0
70 19.5 21.8 24.1 26.4 28.8 31.1 33.4 34.1 34.9 35.6 36.3
75 15.1 18.0 20.8 23.6 26.5 29.3 32.1 33.0 33.9 34.7 35.6
80 10.8 14.1 17.4 20.8 24.1 27.5 30.8 31.8 32.9 33.9 34.9
85 6.4 10.3 14.1 18.0 21.8 25.7 29.5 30.7 31.9 33.0 34.2
90 - 6.3 10.2 14.1 18.0 21.9 25.8 27.5 29.1 30.8 32.5
95 - - 6.3 10.2 14.2 18.1 22.1 24.2 26.4 28.5 30.7
100 - - 5.4 8.4 11.4 14.4 17.4 20.1 22.8 25.5 28.2
105 - - - 6.6 8.7 10.7 12.7 16.0 19.2 22.4 25.7
110 ----5.97.08.011.815.619.423.2
115 -------7.712.016.420.7
TABLE 15: SUPERHEAT CHARGING TABLE FOR D1NH036
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 1,200 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 32.4 33.0 33.5 34.0 34.6 35.1 35.6 35.7 35.8 35.9 36.0
70 29.1 29.8 30.5 31.2 31.9 32.6 33.3 33.6 33.9 34.2 34.4
75 25.7 26.6 27.5 28.4 29.3 30.1 31.0 31.5 31.9 32.4 32.8
80 22.4 23.5 24.5 25.6 26.6 27.7 28.7 29.3 30.0 30.6 31.2
85 19.1 20.3 21.5 22.7 24.0 25.2 26.4 27.2 28.0 28.8 29.6
90 13.5 15.2 16.8 18.5 20.2 21.9 23.6 24.8 26.0 27.2 28.4
95 7.9 10.0 12.2 14.3 16.4 18.6 20.7 22.3 24.0 25.6 27.2
100 6.4 8.0 9.6 11.3 12.9 14.5 16.2 18.4 20.7 23.0 25.2
105 - 6.0 7.1 8.2 9.3 10.5 11.6 14.5 17.4 20.3 23.3
110 - - - 5.2 5.8 6.4 7.1 10.6 14.2 17.7 21.3
115 -------6.710.915.119.3
