York F*FP User Manual

295421-YTG-B-0707
8 Unitary Products Group
ELECTRICAL DATA - 1∅ - 208/230 - 1-60
Models
Heater
1
Model
1. 0 or as follows: 0 = No Breaker, 1 = Breaker.
MAX. STATIC
& MIN. CFM
Total Heat
2
2. See Conversion Table below:
KW Staging
3
3. If first stage heat or 66 is connected to W1, otherwise refer to this table.
KW MBH W1 Only W2 Only W1 + W2
Static Tap 208V 240V 208V 240V 208V 240V 208V 240V 208V 240V
F4FP024H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
F4FP030H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B High 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
F4FP036H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16501906B
4
4. 2HK16501906B only applies to F4FP036 Model.
High 13.2 17.6 45.1 60.1 2.8 3.8 10.4 13.8 13.2 17.6
F4FP040H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B High 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
F4FP042H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Low 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
F4FP045H06T2*
2HK*6500506B
0.5
Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK*6500806B Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Med 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B High 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
F5FP048H06T2*
2HK16500506B
0.5
Med-Low 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK16500806B Med-Low 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B Med-Low 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med-Low 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16502006B Med-Low 15.0 20.0 51.2 68.3 3.8 5.0 11.3 10.0 15.0 20.0
2HK16502506B Med-Low 18.8 25.0 64.2 85.3 3.8 5.0 11.3 15.0 18.8 25.0
F5FP060H06T2*
2HK*6501006B
0.5
Med 3.8 5.0 13.0 17.1 3.8 5.0 3.8 5.0 3.8 5.0
2HK16500806B Med 5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK16501006B Med 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B Med 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16502006B Med 15.0 20.0 51.2 68.3 3.8 5.0 7.5 10.0 15.0 20.0
2HK16502506B Med 18.8 25.0 64.2 85.3 3.8 5.0 11.3 15.0 18.8 25.0
F4FV060H06T2*
2HK*6500806B
0.5
1335
5.6 7.5 19.1 25.6 3.8 5.0 5.6 7.5 5.6 7.5
2HK*6501006B 1335 7.5 10.0 25.6 34.1 3.8 5.0 7.5 10.0 7.5 10.0
2HK16501506B 1335 11.3 15.0 38.6 51.2 3.8 5.0 7.5 10.0 11.3 15.0
2HK16502006B
1335 15.0 20.0 51.2 68.3 3.8 5.0 7.5 10.0 15.0 20.0
2HK16502506B 1335 18.8 25.0 64.2 85.3 3.8 5.0 11.3 15.0 18.8 25.0
NOTE: All models available with factory installed horizontal drain pan.
KW & MBH CONVERSIONS - FOR TOTAL POWER INPUT REQUIREMENT
FOR 230V OPERATION MULTIPLY 240V TABULATED KW & MBH BY .918
