York H2RA036S06 User Manual

036-21121-002 Rev. B (0103)
12 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H1RA024S06
INDOOR COIL MODEL NO. G1FA024S14, 17
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 600 800 1000
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75
T.C. 28.3 25.9 22.7 21.4 28.7 25.1 24.4 21.8 27.5 26.6 24.5 20.9
S.C. 16.9 16.9 15.4 17.0 17.7 16.8 17.0 17.8 17.1 18.0 17.3 17.3
K.W 2.04 1.94 1.78 1.78 2.05 1.87 1.89 1.80 1.97 1.98 1.89 1.72
85
T.C. 28.5 26.0 22.8 21.4 28.9 25.2 24.4 21.8 27.7 26.7 24.6 20.9
S.C. 17.5 17.5 16.0 17.6 18.5 17.6 17.9 18.7 18.0 19.0 18.2 18.3
K.W 2.25 2.14 1.95 1.95 2.28 2.06 2.07 1.96 2.18 2.18 2.07 1.88
95
T.C. 26.9 24.5 21.4 20.1 27.3 23.7 23.0 20.6 26.2 25.2 23.0 19.8
S.C. 17.4 17.4 15.9 17.5 18.5 17.6 17.9 18.8 18.1 19.0 18.3 18.4
K.W 2.42 2.28 2.06 2.06 2.44 2.20 2.20 2.08 2.34 2.32 2.21 1.99
105
T.C. 24.7 22.4 19.5 18.3 24.8 21.6 20.9 18.6 23.8 22.8 21.1 17.9
S.C. 16.8 16.8 15.3 16.9 17.9 16.9 17.3 17.9 17.6 18.4 17.6 17.5
K.W 2.52 2.37 2.15 2.14 2.54 2.30 2.29 2.17 2.43 2.43 2.30 2.07
115
T.C. 22.0 19.9 17.4 16.3 22.2 19.3 18.6 16.9 21.2 20.4 18.8 16.2
S.C. 15.8 15.7 14.3 15.8 17.0 16.2 16.2 16.7 16.7 17.5 16.8 16.1
K.W 2.60 2.45 2.23 2.20 2.63 2.36 2.37 2.25 2.51 2.50 2.37 2.17
125
T.C. 19.4 17.5 15.3 14.2 19.5 16.9 16.3 15.1 18.6 17.9 16.5 14.6
S.C. 14.7 14.7 13.3 14.6 16.0 15.4 15.1 15.4 15.9 16.6 15.9 14.6
K.W 2.68 2.53 2.31 2.26 2.71 2.43 2.44 2.33 2.59 2.57 2.44 2.27
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1AHB0806 G2FD024(S,H)14,17 0.98 0.98 0.91
N1AHB0806 G2FD030(S,H)17 1.00 1.00 0.93
F2RP/F2FP024 0.94 0.94 0.93
F2RP/F2FP030 0.94 0.95 0.93
G1FA030S14 0.98 0.98 0.91
G1HD024 0.93 0.93 0.94
G1HD036 0.98 0.98 0.89
G1NA030S17H 0.94 0.95 0.94
G1NA030S21B 0.944 0.946 0.939
G1UA024S14,17 0.95 0.95 0.93
G1UA030S14 0.98 0.98 0.91
G1UA036S17,21 1.00 1.00 1.00
G2FD024(S,H)14,17 0.98 0.98 0.91
G2FD030(S,H)17 1.00 1.00 0.93
G2FD035(S,H)14 1.00 1.00 0.93
G2FD036(S,H)17 1.02 1.02 0.94

York H2RA036S06 Specifications

General

Model	H2RA036S06
Tonnage	3 Ton
SEER	16
Refrigerant	R-410A
Phase	1
Type	Air Conditioner
Cooling Capacity	36000 BTU/h
Voltage	208/230V
Heating Capacity	36000 BTU/h
Power Supply	208/230V, 1 Phase, 60Hz
Outdoor Unit Dimensions (H x W x D)	31.5 inches
