York HMH7 Series User Manual

Heating performance data - 3 ton
Table 12: Heating performance data - 3 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B361S
ID CFMAir temperature (°F)
900 1200 1500
Entering
outdoor unit
Entering
indoor coil
MBH COP kW MBH COP kW MBH COP kW
60 41.6 3.51 3.47 43.6 3.81 3.36 45.7 4.12 3.25
70 39.1 3.03 3.78 40.2 3.23 3.65 41.3 3.45 3.51
60
80 38.5 2.78 4.07 40.7 3.02 3.95 42.9 3.28 3.83
60 36.4 3.27 3.26 38.2 3.51 3.19 40.1 3.77 3.13
70 34.4 2.85 3.55 35.4 3.00 3.45 36.3 3.16 3.36
47
80 33.7 2.60 3.80 35.6 2.80 3.72 37.4 3.01 3.64
60 33.5 3.12 3.15 35.3 3.34 3.10 37.2 3.56 3.06
70 31.9 2.73 3.42 32.7 2.87 3.35 33.6 3.00 3.28
40
80 31.2 2.49 3.66 32.8 2.67 3.60 34.4 2.85 3.54
60 29.5 2.90 2.99 31.2 3.08 2.97 32.9 3.25 2.96
70 28.3 2.56 3.24 29.0 2.66 3.20 29.7 2.75 3.16
30
80 27.5 2.33 3.46 28.9 2.47 3.43 30.2 2.61 3.40
60 24.3 2.57 2.78 25.8 2.70 2.81 27.3 2.82 2.84
70 23.7 2.31 3.01 24.2 2.35 3.01 24.7 2.40 3.01
17
80 22.7 2.08 3.20 23.7 2.17 3.21 24.7 2.26 3.21
60 21.5 2.37 2.66 22.9 2.47 2.72 24.3 2.58 2.77
70 21.2 2.15 2.88 21.6 2.18 2.90 21.9 2.20 2.92
10
80 20.1 1.93 3.06 21.0 1.99 3.09 21.8 2.05 3.11
60 17.5 2.05 2.50 18.8 2.13 2.59 20.0 2.20 2.67
70 17.6 1.91 2.70 17.8 1.90 2.76 18.1 1.89 2.81
0
80 16.5 1.69 2.86 17.0 1.71 2.91 17.6 1.74 2.97
Note:
• All capacities include indoor fan heat. kW values are for the system (outdoor + indoor).
Performance data - 4 ton
Cooling performance data - 4 ton
Table 13: Cooling performance data - 4 ton - air temperature (°F) entering outdoor unit
Outdoor unit model: HMH72B481S
ID CFM 1200 1500 1800
ID DB
(°F)
80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
Air
temp
(°F)
ID WB
(°F)
57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
T.C. 41.2 50.0 49.7 55.2 58.7 44.7 49.9 51.0 57.7 61.6 48.3 49.8 52.2 60.1 64.4
S.C. 41.2 31.9 35.7 36.3 28.0 44.7 40.9 39.2 39.5 30.3 48.3 49.8 42.7 42.8 32.6
55
kW 2.92 2.96 2.96 3.00 3.08 3.06 3.08 3.08 3.12 3.18 3.21 3.21 3.19 3.23 3.28
T.C. 39.2 46.9 47.1 52.5 56.4 41.6 46.4 48.1 54.7 58.8 44.0 45.9 49.2 56.9 61.2
S.C. 39.2 30.1 34.7 35.0 27.2 41.6 38.0 38.3 38.3 29.5 44.0 45.9 41.8 41.6 31.7
65
kW 3.31 3.35 3.35 3.40 3.51 3.46 3.48 3.48 3.52 3.62 3.60 3.61 3.60 3.65 3.73
T.C. 37.3 43.7 44.4 49.7 54.0 38.5 42.9 45.3 51.7 56.0 39.8 42.0 46.2 53.6 58.1
S.C. 37.3 28.2 33.6 33.7 26.5 38.5 35.1 37.2 36.9 28.6 39.8 42.0 40.8 40.2 30.8
75
kW 3.70 3.75 3.75 3.79 3.94 3.85 3.88 3.88 3.93 4.06 4.00 4.01 4.01 4.06 4.18
T.C. 35.3 40.6 41.7 47.0 51.7 35.4 39.4 42.5 48.7 53.3 35.6 38.1 43.3 50.4 54.9
S.C. 35.3 26.3 32.4 32.3 25.7 35.4 32.2 36.0 35.5 27.7 35.6 38.1 39.5 38.7 29.8
85
kW 4.09 4.14 4.14 4.19 4.37 4.24 4.27 4.28 4.33 4.50 4.39 4.41 4.42 4.47 4.63
T.C. 33.3 37.4 39.0 44.2 49.3 32.3 35.8 39.7 45.7 50.5 31.4 34.2 40.3 47.2 51.7
S.C. 33.3 24.4 31.1 30.8 24.9 32.3 29.3 34.6 34.0 26.8 31.4 34.2 38.1 37.2 28.7
95
kW 4.48 4.53 4.53 4.58 4.79 4.64 4.67 4.68 4.73 4.93 4.79 4.81 4.83 4.89 5.07
YORK Technical Guide: HMH7 Series - 17 SEER Horizontal Discharge Modulating Heat Pump18
