York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 105
YCE48B21S TM9Y100C20MP11 21.0 CF/CM/CU60D 1350 47.5 35.0 15.25 12.75
YCE48B21S TM9Y100C20MP11 21.0 CF/CM64D 1350 47.5 34.2 15.25 12.75
YCE48B21S TM9Y100C20MP11 21.0 XAF/XAUC48F 1525 47.5 33.0 14.00 11.75
YCE48B21S TM9Y100C20MP11 21.0 XAF/XAUC60G 1525 48.0 33.8 14.25 12.00
YCE48B21S TM9Y100C20MP11 24.5 XAF/XAUD60G 1550 47.5 33.8 14.25 12.00
YCE48B21S TM9Y100C20MP11 24.5 XAFD48F 1525 47.0 33.0 14.00 11.75
YCE48B21S TM9Y100C20MP11 21.0 XAHC48F 1525 47.0 33.0 14.00 11.75
YCE48B21S TM9Y100C20MP11 21.0 XAHC60G 1550 48.0 33.8 14.25 12.00
YCE48B21S TM9Y100C20MP11 24.5 XAHD48F 1525 47.0 33.0 14.00 11.75
YCE48B21S TM9Y100C20MP11 21.0 XAHD60G 1525 48.0 33.8 14.25 12.00
YCE48B21S TM9Y120D20MP11 24.5 CF/CM/CU48D 1400 47.0 33.6 15.25 12.50
YCE48B21S TM9Y120D20MP11 24.5 CF/CM/CU60D 1400 47.0 34.0 15.50 12.75
YCE48B21S TM9Y120D20MP11 24.5 CF/CM64D 1575 48.0 34.6 15.50 12.75
YCE48B21S TM9Y120D20MP11 24.5 XAF/XAUD60G 1575 48.0 34.0 14.50 12.00
YCE48B21S TM9Y120D20MP11 24.5 XAFD48F 1575 47.5 33.2 14.25 11.75
YCE48B21S TM9Y120D20MP11 24.5 XAHD48F 1550 47.5 33.0 14.25 12.00
YCE48B21S TM9Y120D20MP11 21.0 XAHD60G 1550 48.0 33.8 14.50 12.00
YCE48B21S TMLE080C16MP11 21.0 XAF/XAUC48F 1550 47.5 33.2 14.00 11.75
YCE48B21S TMLE080C16MP11 21.0 XAF/XAUC60G 1575 48.0 34.0 14.25 12.00
YCE48B21S TMLE080C16MP11 24.5 XAF/XAUD60G 1575 47.5 34.0 14.25 12.00
YCE48B21S TMLE080C16MP11 24.5 XAFD48F 1575 47.0 33.2 14.00 11.75
YCE48B21S TMLE080C16MP11 21.0 XAHC48F 1550 47.5 33.2 14.00 11.75
YCE48B21S TMLE080C16MP11 21.0 XAHC60G 1575 48.0 34.0 14.25 12.00
YCE48B21S TMLE080C16MP11 24.5 XAHD48F 1575 47.0 33.2 14.00 11.75
YCE48B21S TMLE080C16MP11 21.0 XAHD60G 1550 48.0 34.0 14.25 11.75
YCE48B21S TMLE080C20MP11 21.0 XAF/XAUC48F 1425 47.0 31.8 14.50 12.25
YCE48B21S TMLE080C20MP11 21.0 XAF/XAUC60G 1450 48.0 33.0 15.00 12.50
YCE48B21S TMLE080C20MP11 24.5 XAF/XAUD60G 1450 47.5 33.0 15.00 12.50
YCE48B21S TMLE080C20MP11 24.5 XAFD48F 1425 46.5 31.8 14.75 12.25
YCE48B21S TMLE080C20MP11 21.0 XAHC48F 1425 47.0 31.8 14.50 12.00
YCE48B21S TMLE080C20MP11 21.0 XAHC60G 1450 48.0 33.0 15.00 12.50
YCE48B21S TMLE080C20MP11 24.5 XAHD48F 1425 46.5 31.8 14.50 12.25
YCE48B21S TMLE080C20MP11 21.0 XAHD60G 1425 48.0 32.8 15.00 12.50
YCE48B21S TMLE100C16MP11 21.0 XAF/XAUC48F 1550 47.5 33.2 14.00 11.75
YCE48B21S TMLE100C16MP11 21.0 XAF/XAUC60G 1575 48.0 34.0 14.25 12.00
YCE48B21S TMLE100C16MP11 24.5 XAF/XAUD60G 1575 47.5 34.0 14.25 12.00
YCE48B21S TMLE100C16MP11 24.5 XAFD48F 1575 47.0 33.2 14.00 11.75
YCE48B21S TMLE100C16MP11 21.0 XAHC48F 1550 47.5 33.2 14.00 11.75
YCE48B21S TMLE100C16MP11 21.0 XAHC60G 1575 48.0 34.0 14.25 12.00
YCE48B21S TMLE100C16MP11 24.5 XAHD48F 1550 47.0 33.2 14.00 11.75
YCE48B21S TMLE100C16MP11 21.0 XAHD60G 1550 48.0 34.0 14.25 11.75
YCE48B21S TMLE100C20MP11 21.0 XAF/XAUC48F 1400 47.0 31.6 14.50 12.25
YCE48B21S TMLE100C20MP11 21.0 XAF/XAUC60G 1425 48.0 32.8 15.00 12.50
YCE48B21S TMLE100C20MP11 24.5 XAF/XAUD60G 1425 47.5 32.8 15.00 12.50
YCE48B21S TMLE100C20MP11 24.5 XAFD48F 1400 46.5 31.6 14.50 12.25
YCE48B21S TMLE100C20MP11 21.0 XAHC48F 1400 47.0 31.6 14.50 12.00
YCE48B21S TMLE100C20MP11 21.0 XAHC60G 1425 48.0 32.8 15.00 12.50
YCE48B21S TMLE100C20MP11 24.5 XAHD48F 1400 46.5 31.6 14.50 12.25
YCE48B21S TMLE100C20MP11 21.0 XAHD60G 1400 48.0 32.4 15.00 12.50
YCE48B21S TMLE120C16MP11 21.0 XAF/XAUC48F 1550 47.5 33.2 14.00 11.75
YCE48B21S TMLE120C16MP11 21.0 XAF/XAUC60G 1575 48.0 34.0 14.50 12.00
YCE48B21S TMLE120C16MP11 24.5 XAF/XAUD60G 1575 47.5 34.0 14.50 12.00
YCE48B21S TMLE120C16MP11 24.5 XAFD48F 1575 47.0 33.2 14.00 11.75
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
