York LX series Technical Guide

5581700-YTG-F-1021
108 Johnson Controls Ducted Systems
YCE48B21S TP9C100C16MP12C 21.0 CF/CM/CU48C 1325 47.0 34.8 15.00 12.50
YCE48B21S TP9C100C16MP12C 21.0 CF/CM/CU48D 1325 47.0 34.8 15.25 12.50
YCE48B21S TP9C100C16MP12C 21.0 CF/CM/CU60C 1325 46.5 34.6 15.00 12.50
YCE48B21S TP9C100C16MP12C 21.0 CF/CM/CU60D 1425 47.0 35.0 15.00 12.50
YCE48B21S TP9C100C16MP12C 21.0 CF/CM64D 1425 46.5 34.8 15.50 12.75
YCE48B21S TP9C100C16MP13C 21.0 CF/CM/CU48C 1325 47.0 34.8 15.00 12.50
YCE48B21S TP9C100C16MP13C 21.0 CF/CM/CU48D 1325 47.0 34.8 15.25 12.50
YCE48B21S TP9C100C16MP13C 21.0 CF/CM/CU60C 1325 46.5 34.6 15.00 12.50
YCE48B21S TP9C100C16MP13C 21.0 CF/CM/CU60D 1425 47.0 35.0 15.00 12.50
YCE48B21S TP9C100C16MP13C 21.0 CF/CM64D 1425 46.5 34.8 15.50 12.75
YCE48B21S TP9C100C16MP13C 21.0 XAF/XAUC48F 1425 47.0 32.0 14.25 12.00
YCE48B21S TP9C100C16MP13C 21.0 XAF/XAUC60G 1425 47.0 32.6 14.75 12.25
YCE48B21S TP9C100C16MP13C 24.5 XAF/XAUD60G 1425 47.0 32.6 14.75 12.25
YCE48B21S TP9C100C16MP13C 24.5 XAFD48F 1425 46.5 31.8 14.25 12.00
YCE48B21S TP9C100C16MP13C 21.0 XAHC48F 1425 47.0 32.0 14.25 11.75
YCE48B21S TP9C100C16MP13C 21.0 XAHC60G 1425 47.0 32.6 14.75 12.25
YCE48B21S TP9C100C16MP13C 24.5 XAHD48F 1425 46.5 31.8 14.25 12.00
YCE48B21S TP9C100C16MP13C 21.0 XAHD60G 1425 47.0 32.6 14.50 12.25
YCE48B21S TP9C100C20MP12C 21.0 CF/CM/CU48C 1350 47.5 35.4 14.75 12.25
YCE48B21S TP9C100C20MP12C 21.0 CF/CM/CU48D 1350 47.5 35.2 15.25 12.50
YCE48B21S TP9C100C20MP12C 21.0 CF/CM/CU60C 1350 47.5 36.8 14.75 12.25
YCE48B21S TP9C100C20MP12C 21.0 CF/CM/CU60D 1350 46.5 36.0 15.25 12.50
YCE48B21S TP9C100C20MP12C 21.0 CF/CM64D 1475 46.5 36.0 15.25 12.75
YCE48B21S TP9C100C20MP13C 21.0 CF/CM/CU48C 1350 47.5 35.4 14.75 12.25
YCE48B21S TP9C100C20MP13C 21.0 CF/CM/CU48D 1350 47.5 35.2 15.25 12.50
YCE48B21S TP9C100C20MP13C 21.0 CF/CM/CU60C 1350 47.5 36.8 14.75 12.25
YCE48B21S TP9C100C20MP13C 21.0 CF/CM/CU60D 1350 46.5 36.0 15.25 12.50
YCE48B21S TP9C100C20MP13C 21.0 CF/CM64D 1475 46.5 36.0 15.25 12.75
YCE48B21S TP9C100C20MP13C 21.0 XAF/XAUC48F 1475 47.0 32.2 14.00 11.75
YCE48B21S TP9C100C20MP13C 21.0 XAF/XAUC60G 1475 47.5 33.4 14.50 12.00
YCE48B21S TP9C100C20MP13C 24.5 XAF/XAUD60G 1475 46.5 33.4 14.50 12.25
YCE48B21S TP9C100C20MP13C 24.5 XAFD48F 1475 46.5 32.2 14.25 12.00
YCE48B21S TP9C100C20MP13C 21.0 XAHC48F 1475 47.0 32.2 14.00 11.75
YCE48B21S TP9C100C20MP13C 21.0 XAHC60G 1475 47.5 33.4 14.50 12.00
YCE48B21S TP9C100C20MP13C 24.5 XAHD48F 1475 46.5 32.2 14.25 12.00
YCE48B21S TP9C100C20MP13C 21.0 XAHD60G 1475 47.0 33.0 14.50 12.00
YCE48B21S TP9C120D20MP12C 24.5 CF/CM/CU48D 1300 46.5 32.4 15.25 12.50
YCE48B21S TP9C120D20MP12C 24.5 CF/CM/CU60D 1300 46.5 32.6 15.50 12.75
YCE48B21S TP9C120D20MP12C 24.5 CF/CM64D 1525 48.0 35.6 15.25 12.50
YCE48B21S TP9C120D20MP13C 24.5 CF/CM/CU48D 1425 46.5 35.6 15.25 12.50
YCE48B21S TP9C120D20MP13C 24.5 CF/CM/CU60D 1575 48.0 37.0 15.50 12.75
YCE48B21S TP9C120D20MP13C 24.5 CF/CM64D 1575 48.0 37.2 15.25 12.50
YCE48B21S TP9C120D20MP13C 24.5 XAF/XAUD60G 1400 48.0 32.6 15.00 12.50
YCE48B21S TP9C120D20MP13C 24.5 XAFD48F 1400 46.5 31.6 14.75 12.25
YCE48B21S TP9C120D20MP13C 24.5 XAHD48F 1400 46.5 31.6 14.50 12.25
YCE48B21S TP9C120D20MP13C 21.0 XAHD60G 1400 48.0 32.4 15.00 12.50
YCE48B21S TPLC080C16MP12C 21.0 CF/CM/CU48C 1425 47.0 34.4 15.00 12.50
YCE48B21S TPLC080C16MP12C 21.0 CF/CM/CU48D 1425 48.0 35.2 15.00 12.50
YCE48B21S TPLC080C16MP12C 21.0 CF/CM/CU60C 1425 47.0 34.8 15.00 12.50
YCE48B21S TPLC080C16MP12C 21.0 CF/CM/CU60D 1425 47.0 34.8 15.25 12.75
YCE48B21S TPLC080C16MP12C 21.0 CF/CM64D 1425 48.0 35.4 15.25 12.75
YCE48B21S TPLC080C16MP13C 21.0 CF/CM/CU48C 1425 47.0 34.4 15.00 12.50
YCE48B21S TPLC080C16MP13C 21.0 CF/CM/CU48D 1425 48.0 35.2 15.00 12.50
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
