York LX series Technical Guide

5581700-YTG-F-1021
112 Johnson Controls Ducted Systems
YCE48B21S YPLC100C16MP13C 24.5 XAHD48F 1425 46.5 32.0 14.25 12.00
YCE48B21S YPLC100C16MP13C 21.0 XAHD60G 1425 47.0 32.6 14.50 12.25
YCE48B21S YPLC100C20MP12C 21.0 CF/CM/CU48C 1425 47.0 35.8 15.00 12.50
YCE48B21S YPLC100C20MP12C 21.0 CF/CM/CU48D 1375 48.0 36.6 15.50 12.75
YCE48B21S YPLC100C20MP12C 21.0 CF/CM/CU60C 1375 47.5 36.4 15.25 12.75
YCE48B21S YPLC100C20MP12C 21.0 CF/CM/CU60D 1475 48.0 37.2 15.00 12.50
YCE48B21S YPLC100C20MP12C 21.0 CF/CM64D 1425 47.5 36.6 15.25 12.50
YCE48B21S YPLC100C20MP13C 21.0 CF/CM/CU48C 1425 47.0 35.8 15.00 12.50
YCE48B21S YPLC100C20MP13C 21.0 CF/CM/CU48D 1375 48.0 36.6 15.50 12.75
YCE48B21S YPLC100C20MP13C 21.0 CF/CM/CU60C 1375 47.5 36.4 15.25 12.75
YCE48B21S YPLC100C20MP13C 21.0 CF/CM/CU60D 1475 48.0 37.2 15.00 12.50
YCE48B21S YPLC100C20MP13C 21.0 CF/CM64D 1425 47.5 36.6 15.25 12.50
YCE48B21S YPLC100C20MP13C 21.0 XAF/XAUC48F 1425 47.0 31.8 14.50 12.00
YCE48B21S YPLC100C20MP13C 21.0 XAF/XAUC60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC100C20MP13C 24.5 XAF/XAUD60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC100C20MP13C 24.5 XAFD48F 1425 46.5 31.8 14.75 12.25
YCE48B21S YPLC100C20MP13C 21.0 XAHC48F 1425 47.0 31.8 14.50 12.00
YCE48B21S YPLC100C20MP13C 21.0 XAHC60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC100C20MP13C 24.5 XAHD48F 1425 46.5 31.8 14.75 12.25
YCE48B21S YPLC100C20MP13C 21.0 XAHD60G 1425 48.0 32.8 15.00 12.50
YCE48B21S YPLC120C20MP12C 21.0 CF/CM/CU48C 1425 47.0 35.8 15.00 12.50
YCE48B21S YPLC120C20MP12C 21.0 CF/CM/CU48D 1375 48.0 36.6 15.50 12.75
YCE48B21S YPLC120C20MP12C 21.0 CF/CM/CU60C 1375 47.5 36.4 15.25 12.75
YCE48B21S YPLC120C20MP12C 21.0 CF/CM/CU60D 1475 48.0 37.2 15.00 12.50
YCE48B21S YPLC120C20MP12C 21.0 CF/CM64D 1425 47.5 36.6 15.25 12.50
YCE48B21S YPLC120C20MP13C 21.0 CF/CM/CU48C 1425 47.0 35.8 15.00 12.50
YCE48B21S YPLC120C20MP13C 21.0 CF/CM/CU48D 1375 48.0 36.6 15.50 12.75
YCE48B21S YPLC120C20MP13C 21.0 CF/CM/CU60C 1375 47.5 36.4 15.25 12.75
YCE48B21S YPLC120C20MP13C 21.0 CF/CM/CU60D 1475 48.0 37.2 15.00 12.50
YCE48B21S YPLC120C20MP13C 21.0 CF/CM64D 1425 47.5 36.6 15.25 12.50
YCE48B21S YPLC120C20MP13C 21.0 XAF/XAUC48F 1425 47.0 31.8 14.50 12.00
YCE48B21S YPLC120C20MP13C 21.0 XAF/XAUC60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC120C20MP13C 24.5 XAF/XAUD60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC120C20MP13C 24.5 XAFD48F 1425 46.5 31.8 14.75 12.25
YCE48B21S YPLC120C20MP13C 21.0 XAHC48F 1425 47.0 31.8 14.50 12.00
YCE48B21S YPLC120C20MP13C 21.0 XAHC60G 1425 47.5 32.8 15.00 12.50
YCE48B21S YPLC120C20MP13C 24.5 XAHD48F 1425 46.5 31.8 14.75 12.25
YCE48B21S YPLC120C20MP13C 21.0 XAHD60G 1425 48.0 32.8 15.00 12.50
YCE60B21S TL8E080C16UH11 21.0 CF/CM64D 1550 56.0 40.5 14.25 12.00
YCE60B21S TL8E080C16UH11 21.0 XAF/XAUC60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TL8E080C16UH11 24.5 XAF/XAUD60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TL8E080C16UH11 24.5 XAF/XAUD60H 1550 55.0 39.0 14.00 11.75
YCE60B21S TL8E080C16UH11 21.0 XAFC60H 1550 55.5 39.0 14.00 11.75
YCE60B21S TL8E080C16UH11 21.0 XAHC60G 1550 55.0 38.5 14.00 11.75
YCE60B21S TL8E080C16UH11 21.0 XAHC60H 1550 55.5 39.0 14.00 11.75
YCE60B21S TL8E080C16UH11 24.5 XAHD60H 1550 55.0 39.0 14.00 11.75
YCE60B21S TL8E100C20UH11 21.0 CF/CM/CU60C 1600 55.0 40.0 14.00 11.75
YCE60B21S TL8E100C20UH11 21.0 CF/CM64D 1600 57.0 41.5 14.50 12.25
YCE60B21S TL8E100C20UH11 21.0 XAF/XAUC60G 1600 55.5 39.0 14.25 12.00
YCE60B21S TL8E100C20UH11 24.5 XAF/XAUD60G 1600 55.5 39.0 14.25 12.00
YCE60B21S TL8E100C20UH11 24.5 XAF/XAUD60H 1600 55.5 39.5 14.25 12.00
YCE60B21S TL8E100C20UH11 21.0 XAFC60H 1600 55.5 39.5 14.25 12.00
YCE60B21S TL8E100C20UH11 21.0 XAHC60G 1600 55.5 39.0 14.25 12.00
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
