York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 121
PSC furnaces use coil only ratings.
YCE60B21S YPLC100C20MP13C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S YPLC100C20MP13C 21.0 CF/CM/CU60D 1625 55.5 41.0 14.50 12.00
YCE60B21S YPLC100C20MP13C 21.0 CF/CM64D 1550 55.5 40.0 14.25 12.20
YCE60B21S YPLC100C20MP13C 21.0 XAF/XAUC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S YPLC100C20MP13C 24.5 XAF/XAUD60G 1550 55.5 38.5 14.25 12.00
YCE60B21S YPLC100C20MP13C 24.5 XAF/XAUD60H 1550 55.5 39.0 14.25 12.00
YCE60B21S YPLC100C20MP13C 21.0 XAFC60H 1550 55.5 39.0 14.25 12.00
YCE60B21S YPLC100C20MP13C 21.0 XAHC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S YPLC100C20MP13C 21.0 XAHC60H 1550 55.5 39.5 14.25 12.00
YCE60B21S YPLC100C20MP13C 21.0 XAHD60G 1550 55.0 38.5 14.25 11.75
YCE60B21S YPLC100C20MP13C 24.5 XAHD60H 1550 55.0 39.0 14.25 12.00
YCE60B21S YPLC120C20MP12C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S YPLC120C20MP12C 21.0 CF/CM/CU60D 1625 55.5 41.0 14.50 12.00
YCE60B21S YPLC120C20MP13C 21.0 CF/CM/CU60C 1625 55.0 41.0 14.00 11.75
YCE60B21S YPLC120C20MP13C 21.0 CF/CM/CU60D 1625 55.5 41.0 14.50 12.00
YCE60B21S YPLC120C20MP13C 21.0 CF/CM64D 1550 55.5 40.0 14.25 12.20
YCE60B21S YPLC120C20MP13C 21.0 XAF/XAUC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S YPLC120C20MP13C 24.5 XAF/XAUD60G 1550 55.5 38.5 14.25 12.00
YCE60B21S YPLC120C20MP13C 24.5 XAF/XAUD60H 1550 55.5 39.0 14.25 12.00
YCE60B21S YPLC120C20MP13C 21.0 XAFC60H 1550 55.5 39.0 14.25 12.00
YCE60B21S YPLC120C20MP13C 21.0 XAHC60G 1550 55.0 38.5 14.25 12.00
YCE60B21S YPLC120C20MP13C 21.0 XAHC60H 1550 55.5 39.5 14.25 12.00
YCE60B21S YPLC120C20MP13C 21.0 XAHD60G 1550 55.0 38.5 14.25 11.75
YCE60B21S YPLC120C20MP13C 24.5 XAHD60H 1550 55.0 39.0 14.25 12.00
1. High efficiency motor furnaces have blower off delay (B.O.D) standard.
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
2. CM coils available with a factory installed horizontal drain pan. Refer to the Price Pages for specific model number.
—= Not Applicable
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
