York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 139
TP9C060B12MP13C CF42B 1.01 1.05 0.93
TP9C060B12MP13C XAF/XAUB30C 1.01 1.07 0.92
TP9C060B12MP13C XAFB24B 1.00 0.99 0.94
TP9C060B12MP13C XAFC30C 1.01 1.07 0.93
TP9C060B12MP13C XAHB24B 1.00 0.99 0.94
TP9C060B12MP13C XAHB30C 1.01 1.03 0.93
TP9C060B12MP13C XAHC30C 1.01 1.07 0.93
TP9C080B12MP12C CF/CM/CU24B 1.01 1.08 0.93
TP9C080B12MP12C CF/CM/CU30B 1.01 1.12 0.93
TP9C080B12MP12C CF/CM/CU36B 1.01 1.05 0.93
TP9C080B12MP12C CF/CM/CU36C 1.01 1.12 0.93
TP9C080B12MP12C CF/CM/CU42C 1.01 1.12 0.93
TP9C080B12MP12C CF/CM24C 1.01 1.08 0.93
TP9C080B12MP12C CF/CM30C 1.01 1.09 0.93
TP9C080B12MP12C CF42B 1.01 1.10 0.93
TP9C080B12MP13C CF/CM/CU24B 1.01 1.08 0.93
TP9C080B12MP13C CF/CM/CU30B 1.01 1.12 0.93
TP9C080B12MP13C CF/CM/CU36B 1.01 1.05 0.93
TP9C080B12MP13C CF/CM/CU36C 1.01 1.12 0.93
TP9C080B12MP13C CF/CM/CU42C 1.01 1.12 0.93
TP9C080B12MP13C CF/CM24C 1.01 1.08 0.93
TP9C080B12MP13C CF/CM30C 1.01 1.09 0.93
TP9C080B12MP13C CF42B 1.01 1.10 0.93
TP9C080B12MP13C XAF/XAUB30C 1.01 1.09 0.91
TP9C080B12MP13C XAFB24B 1.01 1.03 0.93
TP9C080B12MP13C XAFC30C 1.01 1.09 0.93
TP9C080B12MP13C XAHB24B 1.01 1.03 0.93
TP9C080B12MP13C XAHB30C 1.01 1.06 0.91
TP9C080B12MP13C XAHC30C 1.01 1.06 0.93
TP9C080C16MP13C CF/CM/CU36C 1.01 1.19 0.93
TP9C080C16MP13C CF/CM/CU42C 1.01 1.16 0.93
TP9C080C16MP13C CF/CM24C 1.01 1.14 0.97
TP9C080C16MP13C CF/CM30C 1.01 1.18 0.93
TP9C080C16MP13C CF/CM36D 1.01 1.19 0.93
TP9C080C16MP13C CF/CM42D 1.01 1.16 0.93
TP9C080C16MP13C XAFC30C 1.01 1.19 0.94
TP9C080C16MP13C XAHC30C 1.01 1.19 0.94
TP9C100C16MP12C CF/CM/CU36C 1.01 1.15 0.93
TP9C100C16MP12C CF/CM/CU42C 1.01 1.15 0.93
TP9C100C16MP12C CF/CM24C 1.01 1.12 0.93
TP9C100C16MP12C CF/CM30C 1.01 1.15 0.93
TP9C100C16MP12C CF/CM36D 1.01 1.15 0.93
TP9C100C16MP12C CF/CM42D 1.01 1.15 0.93
TP9C100C16MP13C CF/CM/CU36C 1.01 1.15 0.93
TP9C100C16MP13C CF/CM/CU42C 1.01 1.15 0.93
TP9C100C16MP13C CF/CM24C 1.01 1.12 0.93
TP9C100C16MP13C CF/CM30C 1.01 1.15 0.93
TP9C100C16MP13C CF/CM36D 1.01 1.15 0.93
TP9C100C16MP13C CF/CM42D 1.01 1.15 0.93
TP9C100C16MP13C XAFC30C 1.01 1.15 0.92
TP9C100C16MP13C XAHC30C 1.01 1.15 0.92
TPLC060A12MP12C CF/CM/CU24A 1.00 1.01 0.92
TPLC060A12MP12C CF/CM/CU24B 1.01 1.06 0.93
TPLC060A12MP12C CF/CM/CU30A 1.01 1.01 0.93
TPLC060A12MP12C CF/CM/CU30B 1.01 1.05 0.93
TPLC060A12MP12C CF/CM/CU36B 1.01 1.05 0.93
TPLC060A12MP12C CF/CM36A 1.01 1.08 0.93
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW
TPLC060A12MP12C CF42B 1.01 1.10 0.93
TPLC060A12MP13C CF/CM/CU24A 1.00 1.01 0.92
TPLC060A12MP13C CF/CM/CU24B 1.01 1.06 0.93
TPLC060A12MP13C CF/CM/CU30A 1.01 1.01 0.93
TPLC060A12MP13C CF/CM/CU30B 1.01 1.05 0.93
TPLC060A12MP13C CF/CM/CU36B 1.01 1.05 0.93
TPLC060A12MP13C CF/CM36A 1.01 1.08 0.93
TPLC060A12MP13C CF42B 1.01 1.10 0.93
TPLC060A12MP13C XAF/XAUA24B 1.01 1.01 0.95
TPLC060A12MP13C XAF/XAUB30C 1.01 1.02 0.93
TPLC060A12MP13C XAFB24B 1.00 1.00 0.92
TPLC060A12MP13C XAHB24B 1.01 1.06 0.95
TPLC060A12MP13C XAHB30C 1.01 1.09 0.93
TPLC080B12MP12C CF/CM/CU24B 1.01 1.08 0.93
TPLC080B12MP12C CF/CM/CU30B 1.01 1.05 0.93
TPLC080B12MP12C CF/CM/CU36B 1.01 1.05 0.93
TPLC080B12MP12C CF/CM/CU36C 1.01 1.05 0.93
TPLC080B12MP12C CF/CM/CU42C 1.01 1.05 0.93
TPLC080B12MP12C CF/CM24C 1.01 1.08 0.93
TPLC080B12MP12C CF/CM30C 1.01 1.05 0.93
TPLC080B12MP12C CF42B 1.01 1.04 0.93
TPLC080B12MP13C CF/CM/CU24B 1.01 1.08 0.93
TPLC080B12MP13C CF/CM/CU30B 1.01 1.05 0.93
TPLC080B12MP13C CF/CM/CU36B 1.01 1.05 0.93
TPLC080B12MP13C CF/CM/CU36C 1.01 1.05 0.93
TPLC080B12MP13C CF/CM/CU42C 1.01 1.05 0.93
TPLC080B12MP13C CF/CM24C 1.01 1.08 0.93
TPLC080B12MP13C CF/CM30C 1.01 1.05 0.93
TPLC080B12MP13C CF42B 1.01 1.04 0.93
TPLC080B12MP13C XAF/XAUB30C 1.01 1.04 0.91
TPLC080B12MP13C XAFB24B 1.01 1.01 0.95
TPLC080B12MP13C XAFC30C 1.01 1.04 0.93
TPLC080B12MP13C XAHB24B 1.00 0.98 0.94
TPLC080B12MP13C XAHB30C 1.01 1.01 0.93
TPLC080B12MP13C XAHC30C 1.01 1.01 0.93
TPLC080C16MP12C CF/CM/CU36C 1.01 1.16 0.93
TPLC080C16MP12C CF/CM/CU42C 1.01 1.14 0.93
TPLC080C16MP12C CF/CM24C 1.01 1.16 0.93
TPLC080C16MP12C CF/CM30C 1.01 1.14 0.93
TPLC080C16MP12C CF/CM36D 1.01 1.16 0.93
TPLC080C16MP12C CF/CM42D 1.01 1.14 0.93
TPLC080C16MP13C CF/CM/CU36C 1.01 1.16 0.93
TPLC080C16MP13C CF/CM/CU42C 1.01 1.14 0.93
TPLC080C16MP13C CF/CM24C 1.01 1.16 0.93
TPLC080C16MP13C CF/CM30C 1.01 1.14 0.93
TPLC080C16MP13C CF/CM36D 1.01 1.16 0.93
TPLC080C16MP13C CF/CM42D 1.01 1.14 0.93
TPLC080C16MP13C XAFC30C 1.01 1.14 0.92
TPLC080C16MP13C XAHC30C 1.01 1.14 0.92
TPLC100C16MP12C CF/CM/CU36C 1.01 1.16 0.93
TPLC100C16MP12C CF/CM/CU42C 1.01 1.14 0.93
TPLC100C16MP12C CF/CM24C 1.01 1.16 0.93
TPLC100C16MP12C CF/CM30C 1.01 1.14 0.93
TPLC100C16MP12C CF/CM36D 1.01 1.16 0.93
TPLC100C16MP12C CF/CM42D 1.01 1.14 0.93
TPLC100C16MP13C CF/CM/CU36C 1.01 1.16 0.93
TPLC100C16MP13C CF/CM/CU42C 1.01 1.14 0.93
FURNACE MULTIPLIERS - 2 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
