York LX series Technical Guide

5581700-YTG-F-1021
146 Johnson Controls Ducted Systems
TM8Y080C16MP11 XAFC30C 1.01 1.03 0.97
TM8Y080C16MP11 XAFC36D 1.01 1.02 0.97
TM8Y080C16MP11 XAHC30C 1.01 1.03 0.97
TM8Y080C16MP11 XAHC36D 1.01 1.00 0.97
TM8Y100C16MP11 CF/CM/CU36C 1.01 1.07 0.91
TM8Y100C16MP11 CF/CM/CU42C 1.01 1.07 0.91
TM8Y100C16MP11 CF/CM30C 1.01 1.08 0.93
TM8Y100C16MP11 CF/CM36D 1.01 1.07 0.91
TM8Y100C16MP11 CF/CM42D 1.01 1.08 0.91
TM8Y100C16MP11 XAFC30C 1.01 1.03 0.97
TM8Y100C16MP11 XAFC36D 1.01 1.02 0.97
TM8Y100C16MP11 XAHC30C 1.01 1.03 0.97
TM8Y100C16MP11 XAHC36D 1.01 1.00 0.97
TM8Y100C20MP11 CF/CM/CU36C 1.01 1.09 0.91
TM8Y100C20MP11 CF/CM/CU42C 1.01 1.09 0.91
TM8Y100C20MP11 CF/CM30C 1.01 1.10 0.91
TM8Y100C20MP11 CF/CM36D 1.01 1.09 0.91
TM8Y100C20MP11 CF/CM42D 1.01 1.09 0.91
TM8Y100C20MP11 XAFC30C 1.01 1.04 0.97
TM8Y100C20MP11 XAFC36D 1.01 1.02 0.97
TM8Y100C20MP11 XAHC30C 1.01 1.03 0.97
TM8Y100C20MP11 XAHC36D 1.01 1.00 0.97
TM8Y120C20MP11 CF/CM/CU36C 1.01 1.09 0.91
TM8Y120C20MP11 CF/CM/CU42C 1.01 1.09 0.91
TM8Y120C20MP11 CF/CM30C 1.01 1.10 0.91
TM8Y120C20MP11 CF/CM36D 1.01 1.09 0.91
TM8Y120C20MP11 CF/CM42D 1.01 1.09 0.91
TM8Y120C20MP11 XAFC30C 1.01 1.04 0.97
TM8Y120C20MP11 XAFC36D 1.01 1.02 0.97
TM8Y120C20MP11 XAHC30C 1.01 1.03 0.97
TM8Y120C20MP11 XAHC36D 1.01 1.00 0.97
TM9E026A08MP12 CF/CM/CU30B 0.99 1.02 0.99
TM9E026A08MP12 CF/CM/CU36B 1.00 1.02 0.98
TM9E026A08MP12 CF42B 1.01 1.03 0.99
TM9E026A08MP12 XAF/XAUB30C 0.99 0.97 0.99
TM9E026A08MP12 XAF/XAUB36D 0.99 0.96 0.97
TM9E026A08MP12 XAFA30D 0.94 0.94 0.96
TM9E026A08MP12 XAHB30C 0.99 0.97 0.99
TM9E026A08MP12 XAHB36D 0.99 0.94 0.97
TM9E040A10MP12 CF/CM/CU30B 0.99 1.01 0.97
TM9E040A10MP12 CF/CM/CU36B 0.99 0.99 0.95
TM9E040A10MP12 CF/CM36A 0.99 1.00 0.97
TM9E040A10MP12 CF42B 1.00 1.00 0.96
TM9E040A10MP12 XAF/XAUB30C 0.98 0.94 0.96
TM9E040A10MP12 XAF/XAUB36D 0.99 0.93 0.95
TM9E040A10MP12 XAFA30D 0.94 0.94 0.96
TM9E040A10MP12 XAHB30C 0.98 0.94 0.96
TM9E040A10MP12 XAHB36D 0.99 0.94 0.97
TM9E060A10MP12 CF/CM/CU30B 1.00 1.02 0.96
TM9E060A10MP12 CF/CM/CU36B 1.01 1.01 0.97
TM9E060A10MP12 CF/CM36A 0.99 0.99 0.95
TM9E060A10MP12 CF42B 1.00 1.01 0.96
TM9E060A10MP12 XAF/XAUB30C 0.99 0.96 0.95
TM9E060A10MP12 XAF/XAUB36D 0.99 0.93 0.95
TM9E060A10MP12 XAFA30D 0.94 0.94 0.94
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM9E060A10MP12 XAHB30C 0.99 0.94 0.95
TM9E060A10MP12 XAHB36D 0.99 0.94 0.95
TM9E060B12MP11 CF/CM/CU30B 1.00 1.03 0.94
TM9E060B12MP11 CF/CM/CU36B 1.01 1.03 0.95
TM9E060B12MP11 CF/CM/CU36C 1.01 1.04 0.95
TM9E060B12MP11 CF/CM/CU42C 1.01 1.05 0.95
TM9E060B12MP11 CF/CM30C 1.01 1.04 0.95
TM9E060B12MP11 CF42B 1.01 1.04 0.95
TM9E060B12MP12 CF/CM/CU30B 1.01 1.07 0.97
TM9E060B12MP12 CF/CM/CU36B 1.01 1.07 0.97
TM9E060B12MP12 CF/CM/CU36C 1.01 1.07 0.97
TM9E060B12MP12 CF/CM/CU42C 1.01 1.07 0.97
TM9E060B12MP12 CF/CM30C 1.01 1.07 0.97
TM9E060B12MP12 CF42B 1.01 1.07 0.97
TM9E060B12MP12 XAF/XAUB30C 1.01 1.01 0.97
TM9E060B12MP12 XAF/XAUB36D 1.01 1.00 0.97
TM9E060B12MP12 XAFC30C 1.00 1.01 0.96
TM9E060B12MP12 XAFC36D 1.01 1.00 0.97
TM9E060B12MP12 XAHB30C 1.01 1.00 0.97
TM9E060B12MP12 XAHB36D 1.00 0.97 0.96
TM9E060B12MP12 XAHC30C 1.00 1.02 0.96
TM9E060B12MP12 XAHC36D 1.01 0.99 0.97
TM9E080B12MP11 CF/CM/CU30B 1.01 1.04 0.95
TM9E080B12MP11 CF/CM/CU36B 1.01 1.04 0.93
TM9E080B12MP11 CF/CM/CU36C 1.01 1.05 0.93
TM9E080B12MP11 CF/CM/CU42C 1.01 1.06 0.93
TM9E080B12MP11 CF/CM30C 1.01 1.06 0.93
TM9E080B12MP11 CF42B 1.01 1.04 0.93
TM9E080B12MP12 CF/CM/CU30B 0.99 0.98 0.95
TM9E080B12MP12 CF/CM/CU36B 1.00 0.98 0.96
TM9E080B12MP12 CF/CM/CU36C 1.01 1.00 0.97
TM9E080B12MP12 CF/CM/CU42C 1.01 1.01 0.97
TM9E080B12MP12 CF/CM30C 0.99 1.02 0.95
TM9E080B12MP12 CF42B 1.00 0.99 0.96
TM9E080B12MP12 XAF/XAUB30C 1.00 1.01 0.96
TM9E080B12MP12 XAF/XAUB36D 1.00 0.99 0.96
TM9E080B12MP12 XAFC30C 0.99 1.01 0.95
TM9E080B12MP12 XAFC36D 1.01 1.00 0.97
TM9E080B12MP12 XAHB30C 1.00 1.00 0.96
TM9E080B12MP12 XAHB36D 1.00 0.97 0.96
TM9E080B12MP12 XAHC30C 0.99 1.01 0.95
TM9E080B12MP12 XAHC36D 1.01 0.99 0.97
TM9E080C16MP11 CF/CM/CU36C 1.01 1.08 0.93
TM9E080C16MP11 CF/CM/CU42C 1.01 1.08 0.91
TM9E080C16MP11 CF/CM30C 1.01 1.08 0.93
TM9E080C16MP11 CF/CM36D 1.01 1.08 0.93
TM9E080C16MP11 CF/CM42D 1.01 1.08 0.91
TM9E080C16MP12 CF/CM/CU36C 1.01 1.04 0.97
TM9E080C16MP12 CF/CM/CU42C 1.01 1.04 0.97
TM9E080C16MP12 CF/CM30C 1.01 1.04 0.97
TM9E080C16MP12 CF/CM36D 1.01 1.05 0.97
TM9E080C16MP12 CF/CM42D 1.01 1.06 0.97
TM9E080C16MP12 XAFC30C 1.01 0.98 0.97
TM9E080C16MP12 XAFC36D 1.01 0.96 0.97
TM9E080C16MP12 XAHC30C 1.01 0.97 0.97
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
