York LX series Technical Guide

5581700-YTG-F-1021
148 Johnson Controls Ducted Systems
TM9V100C20MP12C XAHC30C 1.01 1.10 0.97
TM9V100C20MP12C XAHC36D 1.01 1.10 0.97
TM9V120D20MP11C CF/CM36D 1.01 1.12 0.91
TM9V120D20MP11C CF/CM42D 1.01 1.11 0.91
TM9V120D20MP12C CF/CM36D 1.01 1.12 0.91
TM9V120D20MP12C CF/CM42D 1.01 1.11 0.91
TM9Y040A10MP11 XAF/XAUB30C 0.98 0.94 0.96
TM9Y060B12MP11 CF/CM/CU30B 1.00 1.03 0.94
TM9Y060B12MP11 CF/CM/CU36B 1.01 1.03 0.95
TM9Y060B12MP11 CF/CM/CU36C 1.01 1.04 0.95
TM9Y060B12MP11 CF/CM/CU42C 1.01 1.05 0.95
TM9Y060B12MP11 CF/CM30C 1.01 1.04 0.95
TM9Y060B12MP11 CF42B 1.01 1.04 0.95
TM9Y060B12MP11 XAF/XAUB30C 1.00 0.97 0.96
TM9Y060B12MP11 XAF/XAUB36D 0.99 0.94 0.95
TM9Y060B12MP11 XAFC30C 0.99 0.97 0.95
TM9Y060B12MP11 XAFC36D 1.00 0.96 0.96
TM9Y060B12MP11 XAHB30C 0.99 0.95 0.95
TM9Y060B12MP11 XAHB36D 0.99 0.93 0.95
TM9Y060B12MP11 XAHC30C 0.99 0.97 0.95
TM9Y060B12MP11 XAHC36D 0.99 0.94 0.95
TM9Y080B12MP11 CF/CM/CU30B 1.01 1.04 0.95
TM9Y080B12MP11 CF/CM/CU36B 1.01 1.04 0.93
TM9Y080B12MP11 CF/CM/CU36C 1.01 1.05 0.93
TM9Y080B12MP11 CF/CM/CU42C 1.01 1.06 0.93
TM9Y080B12MP11 CF/CM30C 1.01 1.06 0.93
TM9Y080B12MP11 CF42B 1.01 1.04 0.93
TM9Y080B12MP11 XAF/XAUB30C 1.01 0.98 0.97
TM9Y080B12MP11 XAF/XAUB36D 1.01 0.97 0.97
TM9Y080B12MP11 XAFC30C 1.00 0.98 0.96
TM9Y080B12MP11 XAFC36D 1.00 0.97 0.96
TM9Y080B12MP11 XAHB30C 1.01 0.98 0.97
TM9Y080B12MP11 XAHB36D 1.00 0.96 0.96
TM9Y080B12MP11 XAHC30C 1.00 0.98 0.96
TM9Y080B12MP11 XAHC36D 1.00 0.97 0.96
TM9Y080C16MP11 CF/CM/CU36C 1.01 1.08 0.93
TM9Y080C16MP11 CF/CM/CU42C 1.01 1.08 0.91
TM9Y080C16MP11 CF/CM30C 1.01 1.08 0.93
TM9Y080C16MP11 CF/CM36D 1.01 1.08 0.93
TM9Y080C16MP11 CF/CM42D 1.01 1.08 0.91
TM9Y080C16MP11 XAFC30C 1.01 1.02 0.97
TM9Y080C16MP11 XAFC36D 1.01 1.00 0.97
TM9Y080C16MP11 XAHC30C 1.01 1.02 0.97
TM9Y080C16MP11 XAHC36D 1.01 1.00 0.97
TM9Y100C16MP11 CF/CM/CU36C 1.01 1.08 0.93
TM9Y100C16MP11 CF/CM/CU42C 1.01 1.08 0.91
TM9Y100C16MP11 CF/CM30C 1.01 1.08 0.93
TM9Y100C16MP11 CF/CM36D 1.01 1.08 0.91
TM9Y100C16MP11 CF/CM42D 1.01 1.09 0.91
TM9Y100C16MP11 XAFC30C 1.01 1.02 0.97
TM9Y100C16MP11 XAFC36D 1.01 1.00 0.97
TM9Y100C16MP11 XAHC30C 1.01 1.02 0.97
TM9Y100C16MP11 XAHC36D 1.01 1.00 0.97
TM9Y100C20MP11 XAFC30C 1.01 1.12 0.97
TM9Y100C20MP11 XAFC36D 1.01 1.09 0.97
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW
TM9Y100C20MP11 XAHC30C 1.01 1.10 0.97
TM9Y100C20MP11 XAHC36D 1.01 1.08 0.97
TM9Y120D20MP11 CF/CM36D 1.01 1.07 0.91
TM9Y120D20MP11 CF/CM42D 1.01 1.07 0.91
TMLE040A12MP11 CF/CM36A 0.99 1.00 0.95
TMLE040A12MP11 XAF/XAUB30C 1.00 0.98 0.96
TMLE040A12MP11 XAF/XAUB36D 0.99 0.96 0.95
TMLE040A12MP11 XAFA30D 0.94 0.93 0.92
TMLE040A12MP11 XAHB30C 1.00 0.97 0.96
TMLE040A12MP11 XAHB36D 0.99 0.94 0.95
TMLE060A12MP11 CF/CM36A 0.99 1.00 0.95
TMLE060A12MP11 XAF/XAUB30C 0.99 0.94 0.95
TMLE060A12MP11 XAF/XAUB36D 0.99 0.96 0.95
TMLE060A12MP11 XAFA30D 0.94 0.93 0.92
TMLE060A12MP11 XAHB30C 0.99 0.97 0.95
TMLE060A12MP11 XAHB36D 0.99 0.94 0.95
TMLE080B12MP11 XAF/XAUB30C 1.01 1.00 0.97
TMLE080B12MP11 XAF/XAUB36D 1.01 0.97 0.97
TMLE080B12MP11 XAFC30C 1.00 1.00 0.96
TMLE080B12MP11 XAFC36D 1.01 0.97 0.97
TMLE080B12MP11 XAHB30C 1.01 0.98 0.97
TMLE080B12MP11 XAHB36D 1.00 0.96 0.96
TMLE080B12MP11 XAHC30C 1.00 0.98 0.96
TMLE080B12MP11 XAHC36D 1.01 0.97 0.97
TMLE080C16MP11 XAFC30C 1.01 1.01 0.97
TMLE080C16MP11 XAFC36D 1.01 0.98 0.95
TMLE080C16MP11 XAHC30C 1.01 1.00 0.97
TMLE080C16MP11 XAHC36D 1.01 0.98 0.95
TMLE080C20MP11 XAFC36D 1.01 1.13 0.97
TMLE080C20MP11 XAHC30C 1.01 1.14 0.97
TMLE080C20MP11 XAHC36D 1.01 1.12 0.97
TMLE100B12MP11 XAF/XAUB30C 1.00 0.95 0.96
TMLE100B12MP11 XAF/XAUB36D 0.99 0.93 0.95
TMLE100B12MP11 XAFC30C 0.99 0.95 0.95
TMLE100B12MP11 XAFC36D 0.99 0.93 0.95
TMLE100B12MP11 XAHB30C 1.00 0.94 0.96
TMLE100B12MP11 XAHB36D 1.00 0.96 0.96
TMLE100B12MP11 XAHC30C 1.00 1.00 0.96
TMLE100B12MP11 XAHC36D 0.99 0.93 0.95
TMLE100C16MP11 XAFC30C 1.01 1.00 0.97
TMLE100C16MP11 XAFC36D 1.01 0.98 0.95
TMLE100C16MP11 XAHC30C 1.01 1.00 0.97
TMLE100C16MP11 XAHC36D 1.01 0.98 0.97
TMLE100C20MP11 XAFC36D 1.01 1.14 0.97
TMLE100C20MP11 XAHC30C 1.01 1.14 0.97
TMLE100C20MP11 XAHC36D 1.01 1.12 0.97
TMLE120C16MP11 XAFC30C 1.01 1.01 0.97
TMLE120C16MP11 XAFC36D 1.01 0.99 0.95
TMLE120C16MP11 XAHC30C 1.01 1.00 0.97
TMLE120C16MP11 XAHC36D 1.01 0.98 0.97
TMLV060A12MP11C CF/CM/CU30A 1.00 1.04 0.96
TMLV060A12MP11C CF/CM/CU30B 1.01 1.04 0.95
TMLV060A12MP11C CF/CM/CU36B 1.01 1.04 0.93
TMLV060A12MP11C CF42B 1.01 1.04 0.93
TMLV060A12MP12C CF/CM/CU30A 1.00 1.04 0.96
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
