York LX series Technical Guide

5581700-YTG-F-1021
Johnson Controls Ducted Systems 151
TPLC100C20MP13C XAFC36D 1.01 1.11 0.97
TPLC100C20MP13C XAHC30C 1.01 1.12 0.97
TPLC100C20MP13C XAHC36D 1.01 1.09 0.97
TPLC120C20MP13C XAFC30C 1.01 1.12 0.97
TPLC120C20MP13C XAFC36D 1.01 1.11 0.97
TPLC120C20MP13C XAHC30C 1.01 1.12 0.97
TPLC120C20MP13C XAHC36D 1.01 1.09 0.97
YP9C060B12MP13C CF/CM/CU30B 1.01 1.05 0.97
YP9C060B12MP13C CF/CM/CU36B 1.01 1.04 0.95
YP9C060B12MP13C CF/CM/CU36C 1.01 1.04 0.95
YP9C060B12MP13C CF/CM/CU42C 1.01 1.05 0.95
YP9C060B12MP13C CF/CM30C 1.01 1.04 0.95
YP9C060B12MP13C CF42B 1.01 1.04 0.95
YP9C060B12MP13C XAF/XAUB30C 1.01 0.98 0.97
YP9C060B12MP13C XAF/XAUB36D 1.01 0.98 0.97
YP9C060B12MP13C XAFC30C 1.00 0.98 0.96
YP9C060B12MP13C XAFC36D 1.01 0.98 0.97
YP9C060B12MP13C XAHB30C 1.00 0.98 0.96
YP9C060B12MP13C XAHB36D 1.00 0.97 0.96
YP9C060B12MP13C XAHC30C 1.00 0.98 0.96
YP9C060B12MP13C XAHC36D 1.01 0.98 0.97
YP9C080B12MP12C CF/CM/CU30B 1.01 1.03 0.95
YP9C080B12MP12C CF/CM/CU36B 1.01 1.03 0.93
YP9C080B12MP12C CF/CM/CU36C 1.01 1.03 0.93
YP9C080B12MP12C CF/CM/CU42C 1.01 1.04 0.93
YP9C080B12MP12C CF/CM30C 1.01 1.03 0.93
YP9C080B12MP12C CF42B 1.01 1.04 0.93
YP9C080B12MP13C CF/CM/CU30B 1.01 1.03 0.95
YP9C080B12MP13C CF/CM/CU36B 1.01 1.03 0.93
YP9C080B12MP13C CF/CM/CU36C 1.01 1.03 0.93
YP9C080B12MP13C CF/CM/CU42C 1.01 1.04 0.93
YP9C080B12MP13C CF/CM30C 1.01 1.03 0.93
YP9C080B12MP13C CF42B 1.01 1.04 0.93
YP9C080B12MP13C XAF/XAUB30C 0.99 0.94 0.95
YP9C080B12MP13C XAF/XAUB36D 0.99 0.93 0.95
YP9C080B12MP13C XAFC30C 0.99 0.94 0.95
YP9C080B12MP13C XAFC36D 0.99 0.93 0.95
YP9C080B12MP13C XAHB30C 0.99 0.94 0.95
YP9C080B12MP13C XAHB36D 1.01 0.97 0.97
YP9C080B12MP13C XAHC30C 0.99 0.94 0.95
YP9C080B12MP13C XAHC36D 0.99 0.93 0.95
YP9C080C16MP13C CF/CM/CU36C 1.01 1.07 0.93
YP9C080C16MP13C CF/CM/CU42C 1.01 1.07 0.93
YP9C080C16MP13C CF/CM30C 1.01 1.07 0.93
YP9C080C16MP13C CF/CM36D 1.01 1.07 0.93
YP9C080C16MP13C CF/CM42D 1.01 1.07 0.91
YP9C080C16MP13C XAFC30C 1.01 1.02 0.97
YP9C080C16MP13C XAFC36D 1.01 1.01 0.97
YP9C080C16MP13C XAHC30C 1.01 1.02 0.97
YP9C080C16MP13C XAHC36D 1.01 1.02 0.97
YP9C100C16MP12C CF/CM/CU36C 1.01 1.05 0.91
YP9C100C16MP12C CF/CM/CU42C 1.01 1.06 0.91
YP9C100C16MP12C CF/CM30C 1.01 1.06 0.93
YP9C100C16MP12C CF/CM36D 1.01 1.05 0.91
YP9C100C16MP12C CF/CM42D 1.01 1.06 0.91
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW
YP9C100C16MP13C CF/CM/CU36C 1.01 1.05 0.91
YP9C100C16MP13C CF/CM/CU42C 1.01 1.06 0.91
YP9C100C16MP13C CF/CM30C 1.01 1.06 0.93
YP9C100C16MP13C CF/CM36D 1.01 1.05 0.91
YP9C100C16MP13C CF/CM42D 1.01 1.06 0.91
YP9C100C16MP13C XAFC30C 1.01 1.00 0.95
YP9C100C16MP13C XAFC36D 1.01 0.98 0.95
YP9C100C16MP13C XAHC30C 1.01 1.00 0.95
YP9C100C16MP13C XAHC36D 1.01 0.99 0.95
YP9C100C20MP12C CF/CM/CU36C 1.01 1.14 0.93
YP9C100C20MP12C CF/CM/CU42C 1.01 1.15 0.93
YP9C100C20MP12C CF/CM30C 1.01 1.13 0.95
YP9C100C20MP12C CF/CM36D 1.01 1.14 0.93
YP9C100C20MP12C CF/CM42D 1.01 1.15 0.93
YP9C100C20MP13C CF/CM/CU36C 1.01 1.14 0.93
YP9C100C20MP13C CF/CM/CU42C 1.01 1.15 0.93
YP9C100C20MP13C CF/CM30C 1.01 1.13 0.95
YP9C100C20MP13C CF/CM36D 1.01 1.14 0.93
YP9C100C20MP13C CF/CM42D 1.01 1.15 0.93
YP9C100C20MP13C XAFC30C 1.01 1.10 0.97
YP9C100C20MP13C XAFC36D 1.01 1.08 0.97
YP9C100C20MP13C XAHC30C 1.01 1.10 0.97
YP9C100C20MP13C XAHC36D 1.01 1.10 0.97
YP9C120D20MP12C CF/CM36D 1.01 1.12 0.91
YP9C120D20MP12C CF/CM42D 1.01 1.11 0.91
YP9C120D20MP13C CF/CM36D 1.01 1.12 0.91
YP9C120D20MP13C CF/CM42D 1.01 1.11 0.91
YPLC060A12MP12C CF/CM/CU30A 1.00 1.04 0.96
YPLC060A12MP12C CF/CM/CU30B 1.01 1.04 0.95
YPLC060A12MP12C CF/CM/CU36B 1.01 1.04 0.93
YPLC060A12MP12C CF/CM36A 1.01 1.04 0.95
YPLC060A12MP12C CF42B 1.01 1.04 0.93
YPLC060A12MP13C CF/CM/CU30A 1.00 1.04 0.96
YPLC060A12MP13C CF/CM/CU30B 1.01 1.04 0.95
YPLC060A12MP13C CF/CM/CU36B 1.01 1.04 0.93
YPLC060A12MP13C CF/CM36A 0.99 0.99 0.95
YPLC060A12MP13C CF42B 1.01 1.04 0.93
YPLC060A12MP13C XAF/XAUB30C 0.99 0.94 0.95
YPLC060A12MP13C XAF/XAUB36D 0.99 0.93 0.95
YPLC060A12MP13C XAFA30D 0.94 0.93 0.92
YPLC060A12MP13C XAHB30C 0.99 0.94 0.95
YPLC060A12MP13C XAHB36D 0.99 0.93 0.95
YPLC080B12MP12C CF/CM/CU30B 0.99 1.00 0.93
YPLC080B12MP12C CF/CM/CU36B 1.01 1.01 0.95
YPLC080B12MP12C CF/CM/CU36C 1.01 1.01 0.95
YPLC080B12MP12C CF/CM/CU42C 1.01 1.01 0.93
YPLC080B12MP12C CF/CM30C 1.00 1.01 0.94
YPLC080B12MP12C CF42B 1.01 1.01 0.95
YPLC080B12MP13C CF/CM/CU30B 0.99 1.00 0.93
YPLC080B12MP13C CF/CM/CU36B 1.01 1.01 0.95
YPLC080B12MP13C CF/CM/CU36C 1.01 1.01 0.95
YPLC080B12MP13C CF/CM/CU42C 1.01 1.01 0.93
YPLC080B12MP13C CF/CM30C 1.00 1.01 0.94
YPLC080B12MP13C CF42B 1.01 1.01 0.95
YPLC080B12MP13C XAF/XAUB30C 0.99 0.96 0.95
FURNACE MULTIPLIERS - 2.5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
