York LX series Technical Guide

5581700-YTG-F-1021
188 Johnson Controls Ducted Systems
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73°F to 87°F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COIL MULTIPLIERS - 5 TON
Air Handler Coil T.C. S.C. kW
— CF/CM/CU60C 1.00 1.00 1.00
— CF/CM/CU60D 1.00 1.00 1.00
— CF/CM64D 1.02 1.02 1.02
— XAF/XAUC60G 0.99 0.98 0.99
— XAF/XAUD60G 0.99 0.98 0.99
— XAF/XAUD60H 1.00 1.00 1.00
— XAFC60H 1.00 1.00 1.00
— XAHC60G 0.99 0.98 0.99
— XAHC60H 1.00 1.00 1.00
— XAHD60G 0.98 0.95 0.98
— XAHD60H 1.00 0.99 1.00
AE60CX21 — 1.00 0.98 0.98
AE60DX21 — 1.03 1.02 0.98
AP60DX22 — 0.97 0.93 0.97
AP60DX23 — 0.97 0.93 0.97
AVC60CX21 — 1.01 1.01 0.99
AVC60DX21 — 1.03 1.00 0.98
ME16CN21 CF/CM60C 1.00 0.98 0.96
ME20DN21 CF/CM60D 1.01 0.98 0.97
ME20DN21 CF/CM64D 1.03 0.99 0.98
MVC16CN21 CF/CM60C 1.02 0.99 0.94
MVC20DN21 CF/CM60D 1.00 0.98 0.98
MVC20DN21 CF/CM64D 1.02 0.99 0.98
FURNACE MULTIPLIERS - 5 TON
Furnaces Coil T.C. S.C. kW
TL8E080C16UH11 CF/CM64D 1.00 0.99 0.98
TL8E080C16UH11 XAF/XAUC60G 0.98 0.94 0.96
TL8E080C16UH11 XAF/XAUD60G 0.98 0.94 0.98
TL8E080C16UH11 XAF/XAUD60H 0.98 0.95 0.96
TL8E080C16UH11 XAFC60H 0.99 0.95 0.96
TL8E080C16UH11 XAHC60G 0.98 0.94 0.96
TL8E080C16UH11 XAHC60H 0.99 0.95 0.96
TL8E080C16UH11 XAHD60H 0.98 0.95 0.96
TL8E100C20UH11 CF/CM/CU60C 0.98 0.98 0.98
TL8E100C20UH11 CF/CM64D 1.02 1.01 0.98
TL8E100C20UH11 XAF/XAUC60G 0.99 0.95 0.97
TL8E100C20UH11 XAF/XAUD60G 0.99 0.95 0.97
TL8E100C20UH11 XAF/XAUD60H 0.99 0.96 0.97
TL8E100C20UH11 XAFC60H 0.99 0.96 0.97
TL8E100C20UH11 XAHC60G 0.99 0.95 0.97
TL8E100C20UH11 XAHC60H 1.00 0.96 0.98
TL8E100C20UH11 XAHD60G 0.99 0.95 0.95
TL8E100C20UH11 XAHD60H 0.99 0.96 0.97
TL9E100C20UH11 CF/CM/CU60C 0.97 0.96 0.97
TL9E100C20UH11 CF/CM64D 1.02 1.01 1.00
TL9E100C20UH11 XAF/XAUC60G 0.98 0.95 0.98
TL9E100C20UH11 XAF/XAUD60G 0.99 0.95 0.99
TL9E100C20UH11 XAF/XAUD60H 0.99 0.96 0.97
TL9E100C20UH11 XAFC60H 1.00 0.98 0.98
TL9E100C20UH11 XAHC60G 0.98 0.95 0.98
TL9E100C20UH11 XAHC60H 1.00 0.98 0.98
TL9E100C20UH11 XAHD60G 0.99 0.95 0.96
TL9E100C20UH11 XAHD60H 0.99 0.96 0.97
TM8E080C16MP11 CF/CM64D 1.01 1.00 0.99
TM8E080C16MP11 XAF/XAUC60G 0.98 0.94 0.96
TM8E080C16MP11 XAF/XAUD60G 0.98 0.94 0.98
TM8E080C16MP11 XAF/XAUD60H 0.98 0.95 0.96
TM8E080C16MP11 XAFC60H 0.99 0.96 0.96
TM8E080C16MP11 XAHC60G 0.98 0.94 0.96
TM8E080C16MP11 XAHC60H 0.99 0.96 0.96
TM8E080C16MP11 XAHD60G 0.98 0.94 0.96
TM8E080C16MP11 XAHD60H 0.98 0.95 0.96
TM8E080C20MP11 CF/CM/CU60C 0.98 0.96 0.98
TM8E080C20MP11 CF/CM64D 1.01 1.00 0.97
TM8E080C20MP11 XAF/XAUC60G 0.99 0.94 0.97
TM8E080C20MP11 XAF/XAUD60G 0.99 0.94 0.97
TM8E080C20MP11 XAF/XAUD60H 0.99 0.95 0.97
TM8E080C20MP11 XAFC60H 1.00 0.96 0.98
TM8E080C20MP11 XAHC60G 0.99 0.94 0.97
TM8E080C20MP11 XAHC60H 1.00 0.96 0.98
TM8E080C20MP11 XAHD60G 0.99 0.98 0.99
TM8E080C20MP11 XAHD60H 0.99 0.95 0.97
TM8E100C16MP11 CF/CM64D 1.01 1.00 0.99
TM8E100C16MP11 XAF/XAUC60G 0.98 0.94 0.96
TM8E100C16MP11 XAF/XAUD60G 0.98 0.94 0.98
TM8E100C16MP11 XAF/XAUD60H 0.98 0.95 0.96
TM8E100C16MP11 XAFC60H 0.99 0.96 0.96
TM8E100C16MP11 XAHC60G 0.98 0.94 0.96
TM8E100C16MP11 XAHC60H 0.99 0.96 0.96
TM8E100C16MP11 XAHD60G 0.98 0.94 0.96
TM8E100C16MP11 XAHD60H 0.98 0.95 0.96
TM8E100C20MP11 CF/CM64D 1.01 0.99 0.97
TM8E100C20MP11 XAF/XAUC60G 0.99 0.98 0.99
TM8E100C20MP11 XAF/XAUD60G 1.00 0.99 1.00
TM8E100C20MP11 XAF/XAUD60H 0.99 1.00 0.98
TM8E100C20MP11 XAFC60H 1.00 1.00 0.98
TM8E100C20MP11 XAHC60G 0.99 0.98 0.99
TM8E100C20MP11 XAHC60H 1.00 1.00 0.98
TM8E100C20MP11 XAHD60G 0.99 0.98 0.99
TM8E100C20MP11 XAHD60H 0.99 1.00 0.98
TM8E120C16MP11 CF/CM64D 1.01 1.00 0.99
TM8E120C16MP11 XAF/XAUC60G 0.98 0.94 0.96
TM8E120C16MP11 XAF/XAUD60G 0.98 0.94 0.98
TM8E120C16MP11 XAF/XAUD60H 0.98 0.95 0.96
TM8E120C16MP11 XAFC60H 0.99 0.96 0.96
TM8E120C16MP11 XAHC60G 0.98 0.94 0.96
TM8E120C16MP11 XAHC60H 0.99 0.96 0.96
TM8E120C16MP11 XAHD60G 0.98 0.94 0.96
TM8E120C16MP11 XAHD60H 0.98 0.95 0.96
TM8E120C20MP11 CF/CM64D 1.01 0.99 0.97
TM8E120C20MP11 XAF/XAUC60G 1.00 0.99 0.98
TM8E120C20MP11 XAF/XAUD60G 1.00 0.99 1.00
TM8E120C20MP11 XAF/XAUD60H 1.00 1.01 0.98
TM8E120C20MP11 XAFC60H 1.01 1.01 0.98
TM8E120C20MP11 XAHC60G 1.00 0.99 0.98
TM8E120C20MP11 XAHC60H 1.01 1.01 0.98
TM8E120C20MP11 XAHD60G 0.99 0.98 0.99
FURNACE MULTIPLIERS - 5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York LX series Specifications

General

Refrigerant	R-410A
Series	LX
Cooling Capacity	1.5 to 5 tons
Warranty	10-year limited warranty
Sound Level	As low as 72 dBA (depending on model)
