Johnson Controls Unitary Products 13
5006167-YTG-F-0517
Dry coil conditions only, tested without filters.
For optimal performance, external static pressures of 0.2" to 0.5" are recommended. Heating applications tested at 0.50” w.c. esp.
AIR FLOW DATA - CFM
1
(208 Volt)
Models
CM Models
Blower
Motor Speed
External Static Pressure (in. WC.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
208 Volt
MP08B
CM18B
High 975 965 953 926 889
772 724
Medium 729 719 700 643 614 540 354
Low 576 561 501 455 407 289 209
CM24B
High 950 944 927 907 876 838 742
Medium 713 703 686 656 591 533 478
Low 560 546 511 448 398 294 208
MP12B
CM30B
High 1459 1410 1342 1275 1200
1129 1022
Medium 1241 1210 1156 1110 1044 1002 917
Low 992 965 940 911 867 822 758
CM36B
High 1487 1438 1383 1315 1245 1150 1073
Medium 1226 1202 1166 1119 1079 1007 945
Low 959 950 925 892 866 818 716
MP14D
CM30D
High 1944 1891 1832 1767 1693 1594 1303
Medium 1518 1494 1470 1425 1377 1186 1071
Low 1208 1198 1180 1155 1019 968 830
CM36D
High 1967 1920 1848 1781 1710 1623 1532
Medium 1520 1508 1486 1446 1398 1203 1101
Low 1207 1202 1176 1156 1028 970 885
CM42D
High 1949 1912 1854 1791 1715 1645 1358
Medium 1538 1521 1492 1458 1406 1265 1144
Low 1197 1190 1179 1128 1052 998 903
MP16C
CM36C
High 1776 1709 1646 1573 1491 1328 1171
Medium 1591 1545 1486 1424 1300 1173 1066
Low 1360 1331 1285 1194 1097 1027 941
CM42C
High 1746 1687 1616 1536 1386 1265 1147
Medium 1564 1507 1451 1388 1246 1148 998
Low 1339 1301 1258 1136 1052 994 876
CM48C
High 1817 1756 1678 1599 1511 1296 1120
Medium 1673 1618 1542 1477 1349 1138 915
Low 1448 1419 1362 1281 1136 1001 948
MP20D
CM42D
High 2035 1994 1922 1858 1781
1658 1562
Medium 1849 1819 1771 1694 1650 1575 1364
Low 1679 1654 1624 1578 1526 1339 1263
CM48D
High 2061 2001 1937 1871 1780 1684 1570
Medium 1867 1835 1786 1727 1653 1563 1328
Low 1678 1657 1615 1572 1518 1441 1235
CM60D
High 2021 1979 1897 1833 1751 1668 1521
Medium 1852 1811 1758 1697 1639 1547 1389
Low 1646 1630 1596 1555 1491 1384 1247
CM64D
High 1867 1832 1784 1729 1652 1572 1462
Medium 1498 1484 1443 1411 1361 1233 1138
Low 1128 1122 1115 1096 1020 967 893
1. Air handler units have been tested to UL 1995 / CSA 22.2 No. 236 standards up to 0.50" WC. external static pressure.
