Dry coil conditions only, tested without filters.
For optimal performance, external static pressures of 0.2" to 0.5" are recommended. Heating applications tested at 0.50” w.c. esp.
AIR FLOW DATA - CFM
1
(230 Volt)
Models CM Models
Blower
Motor Speed
External Static Pressure (in. WC.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
230 Volt
MP08B
CM18B
High 1142 1126 1093 1057 1009
953 852
Medium 855 840 826 798 756 696 594
Low 676 663 638 584 528 482 404
CM24B
High 1105 1088 1060 1030 987 948 859
Medium 825 815 802 780 752 678 591
Low 655 636 616 569 504 467 345
MP12B
CM30B
High 1521 1471 1397 1322 1241
1161 1057
Medium 1369 1329 1281 1224 1166 1092 1015
Low 1130 1107 1071 1029 972 910 842
CM36B
High 1557 1507 1440 1363 1289 1185 1125
Medium 1351 1321 1266 1207 1153 1076 1019
Low 1103 1083 1056 1024 976 928 851
MP14D
CM30D
High 2092 2038 1958 1884 1795 1714 1591
Medium 1725 1697 1634 1598 1534 1454 1179
Low 1374 1366 1339 1316 1250 1070 904
CM36D
High 2099 2040 1980 1903 1814 1680 1605
Medium 1725 1694 1652 1605 1541 1467 1182
Low 1388 1372 1340 1306 1277 1106 1026
CM42D
High 2083 2033 1960 1894 1820 1720 1459
Medium 1690 1662 1623 1587 1534 1460 1233
Low 1399 1393 1370 1338 1269 1159 1073
MP16C
CM36C
High 1850 1785 1705 1625 1541 1373 1242
Medium 1693 1642 1574 1499 1378 1261 1145
Low 1512 1465 1407 1324 1225 1101 1022
CM42C
High 1815 1754 1680 1593 1472 1278 1206
Medium 1670 1613 1554 1473 1311 1210 1082
Low 1488 1445 1376 1259 1181 1056 979
CM48C
High 1886 1818 1739 1646 1567 1348 1163
Medium 1742 1683 1622 1538 1461 1237 1121
Low 1563 1512 1455 1399 1234 1086 1019
MP20D
CM42D
High 2123 2076 2001 1926 1840
1744 1439
Medium 1999 1959 1896 1821 1744 1651 1347
Low 1851 1819 1768 1698 1626 1544 1269
CM48D
High 2178 2107 2034 1953 1878 1775 1604
Medium 2014 1965 1905 1843 1761 1660 1351
Low 1867 1832 1779 1727 1661 1544 1280
CM60D
High 2132 2052 1993 1899 1813 1733 1594
Medium 1985 1941 1872 1798 1729 1648 1507
Low 1848 1810 1758 1695 1627 1548 1355
CM64D
High 2069 2011 1929 1848 1755 1651 1402
Medium 1962 1902 1832 1758 1675 1558 1335
Low 1833 1787 1734 1667 1581 1382 1269
1. Air handler units have been tested to UL 1995 / CSA 22.2 No. 236 standards up to 0.50" WC. external static pressure.
