York MP SERIES User Manual

Johnson Controls Unitary Products 7
5006167-YTG-F-0517
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60
Air Handler
Models
Heater
Models
1,2
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity
MOP.
3
208V 230V 208V 230V
MP08B
6HK(0,1)6500206 10 12.6 13.7 15 15
6HK(0,1)6500506 20 23.4 25.7 25 30
6HK(0,1)6500806 32 36.6 40.3 40 45
6HK(0,1)6501006 40 45.0 49.6 45 50
6HK(1,2)6501306 52 58.2 64.3 60 70
MP12B
6HK(0,1)6500206 10 14.1 15.2 15 20
6HK(0,1)6500506 20 24.9 27.2 25 30
6HK(0,1)6500806 32 38.1 41.8 40 45
6HK(0,1)6501006 40 46.5 51.1 50 60
6HK(1,2)6501306 52 59.7 65.8 60 70
6HK(1,2)6501506 60 68.2 75.0 70 80
6HK(1,2)6501806 72 81.4 89.7 90 90
6HK(1,2)6502006 80 89.8 98.9 90 100
MP14D
6HK(0,1)6500206 10 14.3 15.5 15 20
6HK(0,1)6500506 20 25.1 27.4 30 30
6HK(0,1)6500806 32 38.4 42.1 40 45
6HK(0,1)6501006 40 46.8 51.3 50 60
6HK(1,2)6501306 52 60.0 66.0 60 70
6HK(1,2)6501506 60 68.4 75.2 70 80
6HK(1,2)6501806 72 81.6 89.9 90 90
6HK(1,2)6502006 80 90.0 99.2 90 100
MP16C
6HK(0,1)6500206 10 14.4 15.6 15 20
6HK(0,1)6500506 20 25.3 27.5 30 30
6HK(0,1)6500806 32 38.5 42.2 40 45
6HK(0,1)6501006 40 46.9 51.5 50 60
6HK(1,2)6501306 52 60.1 66.1 70 70
6HK(1,2)6501506 60 68.5 75.4 70 80
6HK(1,2)6501806 72 81.8 90.0 90 90
6HK(1,2)6502006 80 90.2 99.3 90 100
MP20D
6HK(0,1)6500206 10 15.9 17.1 20 20
6HK(0,1)6500506 20 26.8 29.0 30 30
6HK(0,1)6500806 32 40.0 43.7 40 45
6HK(0,1)6501006 40 48.4 53.0 50 60
6HK(1,2)6501306 52 61.6 67.6 70 70
6HK(1,2)6501506 60 70.0 76.9 70 80
6HK(1,2)6501806 72 83.3 91.5 90 100
6HK(1,2)6502006 80 91.7 100.8 100 110
1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.
3. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
