Johnson Controls Unitary Products 5
5006167-YTG-F-0517
CM48C 1400
85/72 108.0 98.4 88.1 73.8
80/67 93.3 82.1 69.7 57.0
75/62 75.9 64.4 53.1 41.9
70/57 60.7 49.9 39.4 32.4
CM48C 1600
85/72 115.2 105.0 93.9 79.0
80/67 88.3 78.2 65.5 52.6
75/62 72.7 60.8 50.1 37.6
70/57 57.7 46.9 36.6 29.7
CM48D 1600
85/72 115.2 105.0 93.9 79.0
80/67 88.3 78.2 65.5 52.6
75/62 72.7 60.8 50.1 37.6
70/57 57.7 46.9 36.6 29.7
CM60C 1800
85/72 115.1 103.0 91.7 78.6
80/67 96.8 85.9 73.7 60.5
75/62 80.7 69.4 57.5 43.5
70/57 58.7 48.9 37.7 32.7
CM60D 1800
85/72 115.1 103.0 91.7 78.6
80/67 96.8 85.9 73.7 60.5
75/62 80.7 69.4 57.5 43.5
70/57 58.7 48.9 37.7 32.7
CM64D 1800
85/72 133.6 118.5 103.2 86.6
80/67 111.4 96.2 80.3 62.8
75/62 90.7 75.1 60.0 43.5
70/57 70.6 56.9 42.5 32.8
1. See Condensing Unit or Heat Pump Technical Guide for Total Cooling Capacity and Sensible Capacity.
2. Airflow is calculated for each system tonnage.
COOLING CAPACITY
1
(Continued)
Models
Rated CFM
2
Entering Air
Dry/Wet Bulb (°F)
MBH@ Evap. Temp. and Corresponding R-410A Pressure (°F/PSIG)
35/107.9 40/118.9 45/130.7 50/143.3
PHYSICAL & ELECTRICAL DATA - COOLING ONLY
Models MP08B MP12B MP14D MP16C MP20D
Blower - Diameter x Width 10 x 8 10 x 8 10 x 10 10 x 10 10 x 10
Motor
HP 1/4 HP 1/2 HP 1/2 HP 1/2 HP 1 HP
Nominal RPM 850 1085 1085 1040 1007
Voltage 208/230 208/230 208/230 208/230 208/230
Full Load Amps @230V 1.4 2.6 2.8 2.9 4.1
Filter
1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 22 x 20 x 1 20 x 20 x 1 22 x 20 x 1
Bottom Rack Kit 1BR01117 1BR01117 1BR01124 1BR01121 1BR01124
Permanent Type Kit 1PF0601 1PF0601 1PF0603 1PF0602 1PF0603
Shipping / Operating Weight (lbs.) 52/51 52/51 75/74 68/67 75/74
1. Field Supplied.
ELECTRICAL DATA - COOLING ONLY
Models
Motor FLA
1
Minimum Circuit Ampacity
MOP
2
MP08B 1.4 1.8
15
MP12B 2.6 3.3
MP14D 2.8 3.5
MP16C 2.9 3.6
MP20D 4.1 5.1
1. FLA = Full Load Amps.
2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the National Electric Code
or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
