York P*HM Technical Guide

Unitary Products Group 7
036-21475-003 Rev. A (0605)
ACCESSORIES
COMBUSTIBLE FLOOR BASE
1CB1312 = For P3DHX12 model
1CB0416 = For P2DHX16 model
COMBUSTIBLE FLOOR BASE
1VP1280 VESTIBULE PANEL FOR P3DHX12F08001
TABLE 10:
BLOWER PERFORMANCE
MODEL
SPEED
TAP
EXTERNAL STATIC PRESSURE, INCHES W.C.
0.20 0.30 0.40 0.50 0.60
P2HMX12F08001
High 1368 1298 1223 1144 1046
Med-Hi 1318 1256 1178 1108 1007
Med-Low 1173 1132 1071 993 909
Low 856 833 791 748 692
P3HMX14F10001
High 1604 1527 1446 1360 1245
Med-Hi 1507 1425 1338 1270 1171
Med-Low 1172 1146 1119 1064 977
Low 810 771 731 690 645
P3HMX20F12001
High 1957 1911 1846 1797 1729
Med-Hi 1764 1730 1695 1640 1584
Med-Low 1677 1658 1603 1565 1506
Low 1446 1446 1446 1404 1315
P4DHX12F08001
High 1505 1444 1359 1291 1196
Med-Hi 1423 1381 1291 1220 1144
Med-Low 1170 1144 1118 1063 1005
Low 813 813 797 763 690
P42DHX16F12001
High 1833 1786 1722 1656 1568
Med-Hi 1747 1689 1630 1569 1495
Med-Low 1648 1604 1542 1486 1438
Low 1535 1494 1456 1406 1346
P3LBX12F08001
High 1444 1337 1220 1117 1020
Med-Hi 1359 1268 1170 1090 975
Med-Low 1063 1034 1005 944 844
Low 730 689 688 644 596
P3LBX14F12001
High 1566 1487 1404 1316 1145
Med-Hi 1487 1404 1339 1245 1036
Med-Low 1222 1197 1174 1092 913
Low 845 845 809 771 690
P2LBX16F14501
High 1810 t1740 1675 1585 1510
Med-Hi 1570 1540 1495 1445 1375
Med-Low 1090 1080 1070 1065 1050
Low 710 700 690 665 650
MODEL
MOTOR PULLEY
TURNS OUT
EXTERNAL STATIC PRESSURE, INCHES W.C.
0.20 0.30 0.40 0.50 0.60
P4LBX20F19001
0 2274 2080 1847 1532 1099
2 2107 1927 1712 1420 1019
4 1939 1775 1576 1308 939
6 1772 1622 1441 1196 859
