York PCG4A24 - Indoor Blower Specifications; Sound Performance; Electrical Data

5005562-YTG-A-0215
Johnson Controls Unitary Products 11
INDOOR BLOWER SPECIFICATIONS
SOUND PERFORMANCE
ELECTRICAL DATA
Model
Motor
HP RPM EFF. SF Frame
24050 1/3 Variable 0.8 1.0 48
24075 1/2 Variable 0.8 1.0 48
30050 1/3 Variable 0.8 1.0 48
30075 1/2 Variable 0.8 1.0 48
36050 1/2 Variable 0.8 1.0 48
36075 1/2 Variable 0.8 1.0 48
36100 3/4 Variable 0.8 1.0 48
42075 3/4 Variable 0.8 1.0 48
42100 3/4 Variable 0.8 1.0 48
48065 3/4 Variable 0.8 1.0 48
48100 3/4 Variable 0.8 1.0 48
48125 3/4 Variable 0.8 1.0 48
60065 1 Variable 0.8 1.0 48
60100 1 Variable 0.8 1.0 48
60125 1 Variable 0.8 1.0 48
Model
(Tons)
Sound Rating
1
dB (A)
1. Rated in accordance with AHRI Standard 270.
Octave Band Centerline Frequency (Hz)
125 250 500 1000 2000 4000 8000
24 75 62.4 61.5 64.2 67 61 57.3 49.6
30 75 60.5 61.6 64.8 66.9 60.9 56.0 49.7
36 74 58.5 61.8 65.4 66.5 60.7 54.8 49.8
42 74 63.5 63.9 62.3 65 64 54.1 46.6
48 74 63.5 63.9 62.3 65 64 54.1 46.6
60 76 72.3 65.0 63.9 64 60 55.5 49.0
Model Voltage
Compressor
OD Fan
Motor
Supply
Blower Motor
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max Fuse
2
/
Breaker
3
Size
(Amps)
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
RLA LRA MCC FLA FLA
24050 208/230-1-60 8.7 45.0 14.4 1.3 2.6 14.8 20
24075 208/230-1-60 8.7 45.0 14.4 1.3 3.8 16.0 20
30050 208/230-1-60 9.8 57.0 15.1 1.3 2.6 16.2 25
30075 208/230-1-60 9.8 57.0 15.1 1.3 3.8 17.4 25
36050, 36075 208/230-1-60 13.0 78.0 23.0 1.3 3.8 21.4 30
36100 208/230-1-60 13.0 78.0 23.0 1.3 5.4 23.0 35
42075, 42100 208/230-1-60 20.0 112.0 28.0 1.3 5.4 31.7 50
48065, 48100, 48125 208/230-1-60 24.3 117.0 34.0 1.7 5.4 34.7 60
60065, 60100, 60125 208/230-1-60 27.1 144.2 38.0 1.7 7.0 42.6 60
