York PCG4A24 - UNIT TYPICAL SLAB ON GROUND INSTALLATION (Gas model shown); UNIT TYPICAL ROOF CURB INSTALLATION (Gas model shown)

Subject to change without notice. Published in U.S.A. 5005562-YTG-A-0215
Copyright © 2015 by Johnson Controls, Inc. All rights reserved. Supersedes: Nothing
York International Corp.
5005 York Drive
Norman, OK 73069
UNIT TYPICAL SLAB ON GROUND INSTALLATION (Gas model shown)
UNIT TYPICAL ROOF CURB INSTALLATION (Gas model shown)
A0325-001
SUPPLY
AIR DUCT
TO POWER SUPPLY
RETURN
AIR DUCT
FIELD-SUPPLIED
DISCONNECT
SWITCH
CONTROL WIRING TO
INDOOR THERMOSTAT
TO GAS
SUPPLY LINE
MANUAL GAS
SHUTOFF VAVLE
CONDENSATE
DRAIN
SUPPLY
AIR DUCT
TO POWER SUPPLY
RETURN
AIR DUCT
FIELD-SUPPLIED
DISCONNECT
SWITCH
CONTROL WIRING TO
INDOOR THERMOSTAT
TO GAS
SUPPLY LINE
MANUAL GAS
SHUTOFF VAVLE
ROOF CURB
ROOF
CONDENSATE
DRAIN
A0326-001
