COOLING PERFORMANCE DATA
PACKAGED UNIT MODEL NO. PCG4A36
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1600 1400 1200
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 45.3 48.1 48.0 53.1 54.6 42.2 46.3 46.2 51.3 53.5 39.2 44.6 44.5 49.5 52.4
S.C. 45.3 43.2 36.0 36.5 27.9 42.2 39.5 33.3 33.4 26.1 39.2 35.8 30.6 30.4 24.4
K.W. 2.15 2.16 2.16 2.15 2.15 2.07 2.07 2.07 2.06 2.05 1.99 1.99 1.99 1.97 1.95
65 / 55
T.C. 42.0 43.7 43.8 48.6 52.4 39.4 42.5 42.4 47.1 51.0 36.8 41.2 41.0 45.6 49.5
S.C. 42.0 40.3 34.1 34.5 26.6 39.4 36.9 31.3 31.5 24.9 36.8 33.5 28.6 28.5 23.1
K.W. 2.39 2.41 2.40 2.41 2.40 2.30 2.31 2.31 2.32 2.31 2.20 2.22 2.22 2.22 2.21
75 / 63
T.C. 38.7 39.3 39.6 44.1 50.1 36.6 38.6 38.5 42.9 48.4 34.5 37.9 37.4 41.7 46.7
S.C. 38.7 37.4 32.1 32.4 25.4 36.6 34.3 29.3 29.5 23.6 34.5 31.1 26.6 26.7 21.8
K.W. 2.63 2.66 2.64 2.67 2.65 2.52 2.55 2.54 2.57 2.56 2.41 2.45 2.44 2.47 2.46
85 / 69
T.C. 35.3 35.4 35.5 39.4 45.0 33.6 34.8 34.8 38.7 43.8 31.9 34.2 34.0 38.0 42.7
S.C. 35.3 34.4 30.0 30.1 23.6 33.6 32.0 27.5 27.5 21.9 31.9 29.5 25.0 25.0 20.2
K.W. 2.87 2.90 2.88 2.93 2.93 2.75 2.79 2.77 2.83 2.83 2.64 2.68 2.67 2.72 2.73
95 / 75
T.C. 31.9 31.5 31.5 34.8 39.8 30.5 31.0 31.0 34.6 39.2 29.2 30.5 30.6 34.3 38.6
S.C. 31.9 31.5 28.0 27.8 21.8 30.5 29.7 25.7 25.5 20.2 29.2 27.9 23.4 23.3 18.7
K.W. 3.11 3.14 3.12 3.20 3.21 2.99 3.02 3.00 3.08 3.10 2.87 2.91 2.89 2.97 2.99
105 / 83
T.C. 26.5 26.8 26.3 29.0 33.7 26.0 26.5 26.2 29.1 33.5 25.5 26.3 26.0 29.2 33.4
S.C. 26.5 26.8 24.0 24.4 19.3 26.0 25.7 22.6 22.8 18.0 25.5 24.5 21.2 21.3 16.7
K.W. 3.43 3.39 3.35 3.43 3.48 3.27 3.27 3.23 3.32 3.37 3.11 3.14 3.11 3.20 3.25
115 / 89
T.C. 21.4 22.3 21.3 23.4 27.7 21.6 22.2 21.4 23.8 28.0 21.8 22.2 21.5 24.2 28.3
S.C. 21.4 22.3 20.2 21.1 17.0 21.6 21.8 19.7 20.2 15.9 21.8 21.3 19.1 19.3 14.8
K.W. 3.74 3.65 3.57 3.67 3.75 3.54 3.50 3.44 3.54 3.63 3.34 3.36 3.32 3.42 3.50
125 / 95
T.C. 16.2 17.7 16.3 17.7 21.7 17.2 17.9 16.7 18.5 22.5 18.2 18.0 17.0 19.2 23.2
S.C. 16.2 17.7 16.3 17.7 14.6 17.2 17.9 16.7 17.6 13.8 18.2 18.0 17.0 17.4 13.0
K.W. 4.05 3.90 3.79 3.90 4.01 3.81 3.74 3.66 3.77 3.88 3.57 3.58 3.53 3.65 3.76
COOLING PERFORMANCE DATA
PACKAGED UNIT MODEL NO. PCG4A42
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1600 1400 1200
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 49.4 50.2 50.2 55.5 61.9 46.5 48.6 48.5 53.7 59.6 43.7 46.9 46.8 51.8 57.3
S.C. 47.8 45.0 38.5 39.6 32.6 45.5 42.1 36.2 37.0 30.7 43.1 39.2 33.9 34.4 28.7
K.W. 2.50 2.52 2.51 2.53 2.56 2.42 2.44 2.43 2.45 2.47 2.35 2.36 2.36 2.38 2.38
65 / 55
T.C. 46.6 47.0 47.0 52.1 58.0 44.4 45.6 45.6 50.5 56.1 42.2 44.1 44.1 48.9 54.1
S.C. 45.5 43.2 36.4 37.7 30.8 43.7 40.5 34.4 35.3 29.2 41.9 37.7 32.5 32.8 27.5
K.W. 2.73 2.76 2.74 2.77 2.80 2.55 2.68 2.66 2.70 2.71 2.36 2.61 2.59 2.62 2.61
75 / 63
T.C. 43.8 43.9 43.7 48.7 54.1 42.2 42.6 42.6 47.4 52.5 40.6 41.3 41.4 46.0 51.0
S.C. 43.3 41.4 34.3 35.9 29.0 41.9 38.8 32.7 33.6 27.6 40.6 36.3 31.0 31.3 26.2
K.W. 2.97 3.00 2.97 3.01 3.04 2.67 2.93 2.89 2.94 2.94 2.38 2.86 2.82 2.87 2.84
85 / 69
T.C. 40.7 41.8 40.1 44.9 50.0 39.3 40.0 39.3 43.8 48.8 38.0 38.2 38.4 42.7 47.6
S.C. 40.4 37.7 32.8 33.9 27.3 39.2 36.1 31.0 31.2 25.9 38.0 34.5 29.3 28.5 24.5
K.W. 3.28 3.30 3.28 3.31 3.36 2.98 3.24 3.20 3.24 3.26 2.69 3.17 3.13 3.18 3.15
95 / 75
T.C. 37.6 39.7 36.5 41.1 46.0 36.5 37.4 35.9 40.2 45.1 35.4 35.1 35.4 39.3 44.1
S.C. 37.6 33.9 31.3 32.0 25.5 36.5 33.3 29.4 28.9 24.1 35.4 32.7 27.6 25.8 22.8
K.W. 3.59 3.60 3.59 3.60 3.67 3.29 3.54 3.51 3.54 3.57 3.00 3.48 3.44 3.48 3.47
105 / 83
T.C. 33.3 34.8 31.8 36.1 40.6 32.5 33.0 31.5 35.5 40.0 31.7 31.2 31.2 34.9 39.4
S.C. 33.3 31.0 28.4 29.5 23.3 32.5 30.3 26.9 27.0 22.1 31.7 29.6 25.4 24.5 20.9
K.W. 4.01 4.03 4.01 4.03 4.09 3.72 3.97 3.94 3.97 3.99 3.44 3.90 3.86 3.90 3.90
115 / 89
T.C. 29.2 30.1 27.3 31.1 35.3 28.7 28.8 27.2 30.9 35.0 28.2 27.4 27.1 30.7 34.7
S.C. 29.2 28.2 25.6 27.2 21.2 28.7 27.4 24.4 25.2 20.1 28.2 26.7 23.3 23.1 19.0
K.W. 4.43 4.45 4.42 4.45 4.50 4.14 4.38 4.35 4.37 4.41 3.86 4.31 4.28 4.30 4.31
125 / 95
T.C. 25.1 25.4 22.8 26.2 30.1 24.9 24.5 22.9 26.4 30.1 24.7 23.7 23.0 26.5 30.1
S.C. 25.1 25.4 22.8 24.8 19.1 24.9 24.5 22.0 23.3 18.1 24.7 23.7 21.2 21.8 17.2
K.W. 4.84 4.86 4.83 4.87 4.91 4.57 4.79 4.76 4.78 4.82 4.29 4.71 4.69 4.70 4.73
