York PCG6B48 Technical Guide

5219967-UTG-A-0716
12 Johnson Controls Unitary Products
COOLING PERFORMANCE DATA - 5 TON (LOW SPEED)
PACKAGED UNIT MODEL NO. PCG6B60
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1100 1300 1500
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 44.6 51.1 50.5 55.7 59.9 47.1 53.0 51.7 57.4 61.8 49.5 54.9 53.0 59.2 63.8
S.C. 44.6 43.1 36.8 36.5 30.0 47.1 47.5 40.0 39.4 31.6 49.5 51.8 43.3 42.4 33.3
K.W. 1.77 1.77 1.77 1.74 1.90 1.87 1.87 1.88 1.84 1.92 1.98 1.98 1.99 1.94 1.94
65 / 55
T.C. 42.1 47.6 46.8 52.1 57.3 44.3 49.4 48.4 53.9 59.6 46.6 51.2 50.1 55.7 61.9
S.C. 42.1 41.4 35.0 34.9 28.5 44.3 45.6 38.1 37.8 30.2 46.6 49.9 41.2 40.8 31.9
K.W. 2.05 2.05 2.14 2.11 2.08 2.15 2.15 2.20 2.16 2.14 2.25 2.24 2.25 2.22 2.20
75 / 63
T.C. 39.6 44.2 43.1 48.5 54.8 41.6 45.8 45.1 50.3 57.4 43.7 47.4 47.1 52.1 60.1
S.C. 39.6 39.6 33.3 33.3 26.9 41.6 43.8 36.2 36.2 28.7 43.7 47.4 39.1 39.2 30.4
K.W. 2.34 2.33 2.51 2.48 2.26 2.43 2.42 2.51 2.48 2.36 2.52 2.51 2.52 2.49 2.45
85 / 69
T.C. 36.5 40.6 39.8 44.8 50.8 38.3 41.8 41.5 46.3 53.0 40.1 43.0 43.2 47.9 55.1
S.C. 36.5 37.6 31.4 31.4 25.1 38.3 40.9 34.2 34.3 26.8 40.1 43.0 37.0 37.2 28.6
K.W. 2.69 2.67 2.87 2.74 2.61 2.78 2.77 2.87 2.79 2.71 2.87 2.88 2.88 2.84 2.81
95 / 75
T.C. 33.4 37.0 36.4 41.0 46.9 35.0 37.8 37.8 42.3 48.5 36.5 38.6 39.3 43.6 50.2
S.C. 33.4 35.5 29.5 29.5 23.2 35.0 37.8 32.2 32.3 25.0 36.5 38.6 34.9 35.1 26.7
K.W. 3.04 3.02 3.23 3.00 2.96 3.13 3.13 3.23 3.10 3.07 3.22 3.25 3.24 3.20 3.17
105 / 83
T.C. 30.0 34.0 32.7 36.5 42.1 31.3 34.3 33.6 37.3 43.3 32.7 34.6 34.5 38.1 44.6
S.C. 30.0 32.8 27.2 27.4 21.2 31.3 34.3 29.6 30.1 22.7 32.7 34.6 32.0 32.9 24.3
K.W. 3.56 3.48 3.62 3.46 3.43 3.62 3.59 3.66 3.56 3.53 3.69 3.70 3.70 3.66 3.63
115 / 89
T.C. 26.7 31.1 29.0 32.1 37.4 27.8 30.9 29.4 32.5 38.3 28.9 30.6 29.9 32.8 39.1
S.C. 26.7 30.3 25.0 25.4 19.2 27.8 30.9 27.1 28.0 20.6 28.9 30.6 29.2 30.7 21.9
K.W. 4.07 3.93 4.00 3.91 3.87 4.10 4.03 4.07 4.01 3.98 4.13 4.13 4.14 4.11 4.09
125 / 95
T.C. 23.4 28.3 25.3 27.7 32.7 24.3 27.5 25.3 27.6 33.2 25.1 26.7 25.2 27.5 33.7
S.C. 23.4 27.7 22.8 23.4 17.2 24.3 27.5 24.6 25.9 18.4 25.1 26.7 25.2 27.5 19.6
K.W. 4.57 4.38 4.39 4.35 4.32 4.58 4.47 4.49 4.46 4.43 4.58 4.57 4.59 4.56 4.54
COOLING PERFORMANCE DATA - 5 TON (HIGH SPEED)
PACKAGED UNIT MODEL NO. PCG6B60
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1600 1800 2000
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 59.2 68.9 66.5 71.8 77.1 61.3 70.6 67.6 73.5 77.7 63.5 72.3 68.8 75.1 78.3
S.C. 59.2 55.8 47.0 46.7 37.2 61.3 59.6 49.6 49.1 38.2 63.5 63.4 52.2 51.5 39.1
K.W. 2.80 2.86 2.87 3.21 2.93 3.03 3.08 3.08 3.28 3.14 3.26 3.30 3.30 3.34 3.35
65 / 55
T.C. 54.3 64.1 61.7 68.4 74.2 55.7 66.1 63.2 69.9 75.5 57.2 68.1 64.7 71.3 76.9
S.C. 54.3 53.9 45.4 44.9 35.7 55.7 42.9 51.1 47.3 46.7 57.2 31.9 56.8 49.8 57.8
K.W. 3.07 3.25 3.13 3.34 3.37 3.30 3.34 3.35 3.48 3.51 3.53 3.42 3.56 3.62 3.66
75 / 63
T.C. 49.3 59.2 57.0 65.1 71.3 50.1 61.6 58.8 66.3 73.4 50.9 64.0 60.6 67.4 75.4
S.C. 49.3 52.0 43.7 43.0 34.2 50.1 26.2 52.5 45.5 55.3 50.9 0.3 60.6 48.0 75.4
K.W. 3.33 3.65 3.39 3.47 3.81 3.57 3.60 3.61 3.68 3.89 3.80 3.55 3.83 3.90 3.97
85 / 69
T.C. 48.7 55.4 53.9 60.5 67.1 47.8 57.3 55.3 61.5 68.6 46.8 59.2 56.8 62.4 70.2
S.C. 48.7 49.6 41.4 41.0 32.2 47.8 38.2 47.0 43.3 43.3 46.8 26.7 52.7 45.7 54.5
K.W. 3.71 3.87 3.74 3.95 4.02 3.94 3.96 3.96 4.10 4.17 4.16 4.04 4.17 4.25 4.32
95 / 75
T.C. 48.0 51.6 50.7 55.9 62.8 45.4 53.0 51.8 56.7 63.9 42.8 54.3 53.0 57.4 64.9
S.C. 48.0 47.2 39.1 39.1 30.3 45.4 50.1 41.5 41.2 31.4 42.8 53.0 43.9 43.3 32.6
K.W. 4.09 4.10 4.09 4.44 4.23 4.30 4.31 4.30 4.52 4.44 4.52 4.53 4.51 4.60 4.66
105 / 83
T.C. 42.5 46.6 45.9 50.9 57.9 40.7 48.1 47.1 51.6 58.7 38.9 49.5 48.3 52.3 59.6
S.C. 42.5 43.9 36.8 36.9 28.2 40.7 46.3 33.0 39.0 29.3 38.9 48.7 29.1 41.1 30.4
K.W. 4.60 4.71 4.61 4.96 4.84 4.82 4.87 4.77 5.04 5.00 5.03 5.04 4.92 5.11 5.17
115 / 89
T.C. 37.0 41.8 41.3 46.0 53.1 36.1 43.4 42.5 46.7 53.8 35.1 44.9 43.8 47.4 54.4
S.C. 37.0 40.7 34.7 34.7 26.2 36.1 42.6 24.7 36.9 27.2 35.1 44.5 14.7 39.0 28.2
K.W. 5.10 5.29 5.12 5.46 5.43 5.32 5.42 5.23 5.54 5.54 5.54 5.54 5.33 5.61 5.66
125 / 95
T.C. 31.6 37.0 36.6 41.1 48.2 31.5 38.6 37.9 41.8 48.8 31.4 40.2 39.3 42.5 49.3
S.C. 31.6 37.0 32.5 32.6 24.2 31.5 38.6 16.4 34.7 25.1 31.4 40.2 0.3 36.8 26.1
K.W. 5.60 5.88 5.63 5.96 6.01 5.82 5.96 5.68 6.04 6.09 6.04 6.04 5.74 6.11 6.16
