5285477-UIM-A-1016
10 Johnson Controls Unitary Products
Table 9: Physical Data
NOMINAL TONNAGE
PHE6B36 PHE6B48 PHE6B60
3.0 4.0 5.0
AHRI Cooling Performance
Gross Capacity @ AHRI A point (MBH) 36.5 49.1 60.0
AHRI net capacity (MBH) 36.0 48.0 58.0
EER 12.5 12.5 12.0
SEER 16.0 16.0 16.0
Nominal CFM 1200 1600 1800
System power (KW) 3.0 3.6 4.6
Refrigerant type R410A R410A R410A
Refrigerant charge (lb-oz) 11-13 12-13 15-8
AHRI Heating Performance
47 Capacity Rating (MBH) 33.8 45.5 56.0
System Power (kW/COP) 3.6 3.7 3.6
17 F Capacity Rating (MBH) 19.6 26.0 32.0
HSPF (BTU/Watts-hr.) 8.0 8.0 8.0
Dimensions (inches)
Length 51-1/4 51-1/4 51-1/4
Width 45-3/4 45-3/4 45-3/4
Height 49 53 55
Operating WT. (lbs.) 448 496 523
Compressors
Type Scroll Scroll Scroll
Stages 2 2 2
Outdoor Coil Data
Face area (Sq. Ft.) 19.5 23.8 25.9
Rows 2 2 2
Fins per inch 22 22 22
Tube diameter 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV
Table 10 Continued on next page.
Indoor Coil Data
Face area (Sq. Ft.) 6.3 6.3 6.3
Rows 3 3 4
Fins per inch 16 16 16
Tube diameter 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV
Outdoor Fan Data
Fan diameter (Inch) 26 26 26
Type Prop Prop Prop
Drive type Direct Direct Direct
No. speeds 1 1 1
Motor HP each 1/3 1/3 1/3
RPM 850 850 850
Nominal total CFM 3200 3200 3200
Direct Drive Indoor Blower Data
Fan Size (Inch) 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal
Motor HP each 1/2 3/4 1
RPM 1200 Max 1200 Max 1200 Max
Frame size 48 48 48
Filters
Filter size B B B
Quantity - Size
Field-supplied external filters must be sized so as not to exceed 300 fpm air velocity through disposable
filters. For internal filter use, a filter rack kit is available. Consult the instructions supplied with that kit for
replacement filter sizes. Filter sizes: A=20x20, B=20x30.
