SECTION V: AIRFLOW PERFORMANCE
NOTES:
1.Airflow tested with dry coil conditions, without air filters, at 230 volts.
2.Applications above 0.8" w.c. external static pressure are not recommended.
3.Brushless DC high efficiency standard ECM blower motor used for all indoor blower assemblies.
4.Minimal variations in airflow performance data results from operating at 208 volts. Data above may be used in those cases.
5.Minimal variations in airflow performance data results from using downflow duct applications. Data above may be used in those cases.
6. Heating applications tested at 0.50" w.c. esp, and cooling applications tested at 0.30" w.c.esp per standards.
Table 10: Airflow Performance - Side Duct Application
Model Jumper Position
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
PHE6B36
High Cool/Heat
A
1345 1318 1271 1222 1172
1108 1035 961 894 841
B
1264 1211 1170 1115 1056
981 894 826 775 729
C
1232 1178 1131 1077 1012
929 853 790 738 690
D
1058 999 931 859 762
694 635 582 523 459
Low Cool/Heat
A
1153 1095 1036 979 899
810 751 697 643 588
B
1015 952 884 802 709
646 582 528 467 402
C
882 805 741 625 556
501 415 359 297 228
D
805 718 642 523 436
376 294 247 193 118
Electric Heat
A
1190 1133 1079 1026 953
861 798 742 689 638
B
1112 1054 991 928 840
760 701 648 591 532
C
955 886 821 721 642
584 508 453 391 324
D
856 776 708 591 516
459 375 321 262 191
PHE6B48
High Cool/Heat
A
1851 1809 1781 1746 1707
1656 1609 1552 1518 1460
B
1689 1652 1630 1597 1556
1504 1461 1404 1368 1310
C
1614 1578 1554 1520 1477
1424 1382 1324 1286 1228
D
1374 1333 1298 1255 1204
1145 1100 1044 993 933
Low Cool/Heat
A
1473 1435 1406 1368 1320
1264 1220 1164 1119 1060
B
1374 1333 1298 1255 1204
1145 1100 1044 993 933
C
1322 1278 1238 1191 1138
1077 1030 975 920 859
D
1286 1241 1197 1149 1095
1032 984 930 872 810
Electric Heat
A
1441 1407 1373 1325 1279
1232 1182 1108 1042 1039
B
1327 1286 1242 1192 1143
1081 1024 949 881 834
C
1187 1136 1084 1028 968
886 827 767 702 657
D
1087 1031 974 909 832
750 704 653 600 537
PHE6B60
High Cool/Heat
A
2149 2114 2077 2030 1989
1948 1905 1859 1816 1768
B
2013 1977 1941 1898 1860
1816 1772 1726 1677 1630
C
1936 1900 1864 1822 1783
1739 1695 1649 1597 1551
D
1719 1685 1642 1600 1555
1508 1465 1418 1372 1327
Low Cool/Heat
A
1629 1591 1546 1502 1455
1409 1362 1315 1266 1220
B
1558 1516 1469 1423 1375
1329 1280 1232 1181 1135
C
1453 1406 1355 1305 1255
1207 1153 1100 1047 997
D
1410 1361 1307 1255 1204
1155 1100 1044 992 938
Electric Heat
A
1743 1712 1666 1623 1580
1540 1493 1449 1404 1370
B
1485 1436 1380 1329 1283
1234 1185 1139 1084 1032
C
1382 1324 1265 1210 1162
1108 1059 1012 952 891
D
1205 1131 1066 1005 953
892 841 793 724 644
