York Predator DF 090 - Unit Dimensions; Unit Height; Unit Clearances

246699-YTG-D-1208
Johnson Controls Unitary Products 33
FIGURE 5 - UNIT DIMENSIONS
3EE$ETAIL
!
&OR"ASERAIL
$IMENSIONS
3EE$ETAIL"








#ONVENIENCE
0OWER
/UTLET
%NTRY

0OWER
%NTRY


#ONTROL
%NTRY

0OWER
%NTRY

,%&4
&2/.4
&OR$RAIN
$IMENSIONS
3EE$ETAIL#

8
TABLE 34: UNIT HEIGHT
Unit Model Number
X
DF078
50 3/4
DF090
42
DF102
42
DF120
50 3/4
TABLE 35: UNIT CLEARANCES
Top
*
* Units must be installed outdoors. Overhanging structure or
shrubs should not obstruct condenser air discharge outlet.
72”
Right
12”
Front
36”
Left
36”
Rear
†
† To remove the slide-out drain pan, a rear clearance of 60” is
required. If space is unavailable, the drain pan can be
removed through the front by separating the corner wall.
36”
Bottom
‡
‡ Units may be installed on combustible floors made from
wood or class A, B or C roof covering materials.
0”
5 - 1 / 4
B a s e
P a n
1 7 - 1 3 / 1 6
V i e w o f W a l l A c r o s s f r o m C o i l
G a s P i p e I n l e t
DETAIL A
3 - 3 / 4
3 - 9 / 1 6
2 - 3 / 8
DETAIL B
5 - 3 / 8
DETAIL C
