York TCHD18 - Page 10

556454-YTG-B-0410
10 Johnson Controls Unitary Products
TCHD24S41S3
T*9X*B12 HD36 17 790 23.0 17.0 14.00 11.75
T*(8,L)X*A12 UC24A 14 785 23.6 17.3 14.50 12.00
T*(8,L)X*B12 UC24B 17 835 23.6 17.6 14.75 12.00
T*9X*B12 UC24B 17 775 23.6 17.3 14.50 12.00
T*(8,L)X*A12 UC30A 14 785 23.6 17.3 14.50 12.00
T*(8,L)X*B12 UC30B 17 835 23.6 17.6 14.75 12.00
T*9X*B12 UC30B 17 775 23.6 17.3 14.50 12.00
T*(8,L)X*A12 UC36A 14 780 22.8 16.7 14.05 12.00
T*(8,L)X*B12 UC36B 17 835 23.0 17.3 14.35 12.00
T*(8,L)X*C16 UC36C 21 875 23.2 17.6 14.40 12.00
T*9X*B12 UC36B 17 775 22.8 16.7 14.10 12.00
T*9X*C16 UC36C 21 815 23.0 16.9 14.35 12.25
T*9X*C20 UC36C 21 810 22.8 16.8 14.25 12.00
T*(8,L)X*B12 UC42B 17 755 23.6 17.2 14.75 12.25
T*(8,L)X*C16 UC42C 21 725 23.6 17.2 14.50 12.00
T*9X*B12 UC42B 17 805 23.8 17.6 14.50 12.00
T*9X*C16 UC42C 21 805 23.8 17.7 14.75 12.25
T*9X*C20 UC42C 21 790 23.4 17.1 14.25 11.75
T*(8,L)X*C16 UC48C 21 685 23.4 16.8 14.50 12.00
T*9X*C16 UC48C 21 770 23.6 17.6 14.40 12.25
T*9X*C20 UC48C 21 815 24.0 18.0 14.50 12.00
(Y*(8,L)C/T*8V)*A12 FC/MC/PC24A 14 805 23.6 17.3 14.50 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC24B 17 815 23.6 17.5 14.75 12.25
Y*9C*B12 FC/MC/PC24B 17 790 23.4 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 805 23.6 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 815 23.6 17.3 14.70 12.30
Y*9C*B12 FC/MC/PC30B 17 790 23.6 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 775 23.6 17.5 14.20 12.00
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 760 23.6 17.1 14.50 12.20
Y*9C*B12 FC/MC/PC35B 17 815 23.8 17.6 14.30 12.15
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 855 24.0 18.1 14.75 12.45
(Y*(8,L)C/T*8V)*C20 FC/MC/PC35C 21 740 23.6 17.2 14.90 12.55
Y*9C*C16 FC/MC/PC35C 21 900 24.2 18.5 14.60 12.35
Y*9C*C20 FC/MC/PC35C 21 755 23.6 17.2 14.65 12.35
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 805 23.6 17.4 14.50 12.15
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 765 23.8 17.5 14.75 12.35
Y*9C*B12 FC/MC/PC36B 17 815 23.6 17.4 14.50 12.15
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 855 24.0 18.1 14.85 12.50
(Y*(8,L)C/T*8V)*C20 FC/MC/PC36C 21 750 23.6 17.1 14.90 12.50
Y*9C*C16 FC/MC/PC36C 21 785 23.8 17.5 14.75 12.35
Y*9C*C20 FC/MC/PC36C 21 760 23.6 17.2 14.75 12.35
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 805 24.0 17.7 14.40 12.15
(Y*(8,L)C/T*8V)*B12 FC/MC/PC43B 17 760 24.0 17.4 14.70 12.45
Y*9C*B12 FC/MC/PC43B 17 800 24.0 17.8 14.60 12.30
(Y*(8,L)C/T*8V)*C16 FC/MC/PC43C 21 895 24.4 18.9 14.90 12.60
(Y*(8,L)C/T*8V)*C20 FC/MC/PC43C 21 760 24.0 17.5 15.05 12.70
Y*9C*C16 FC/MC/PC43C 21 810 24.2 18.0 14.75 12.45
Y*9C*C20 FC/MC/PC43C 21 890 24.4 18.8 14.85 12.50
(Y*(8,L)C/T*8V)*C16 FC/MC/PC48C 21 815 24.4 18.4 15.15 12.80
Y*9C*C16 FC/MC/PC48C 21 890 24.6 19.1 15.00 12.60
(Y*(8,L)C/T*8V)*A12 HC18 14 775 22.8 16.5 14.00 11.65
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
