York TCHD18 - Page 11

556454-YTG-B-0410
Johnson Controls Unitary Products 11
TCHD24S41S3
(Y*(8,L)C/T*8V)*A12 HC30 14 775 23.4 17.2 14.10 12.00
(Y*(8,L)C/T*8V)*B12 HC36 17 760 23.6 17.1 14.50 12.20
Y*9C*B12 HC36 17 815 23.8 17.6 14.35 12.15
(Y*(8,L)C/T*8V)*C16 HC42 21 895 24.4 18.9 14.90 12.60
(Y*(8,L)C/T*8V)*C20 HC42 21 760 24.0 17.5 15.05 12.70
Y*9C*C16 HC42 21 810 24.2 18.0 14.75 12.45
Y*9C*C20 HC42 21 890 24.4 18.9 14.85 12.50
(Y*(8,L)C/T*8V)*A12 HD24 14 805 24.0 17.6 14.60 12.30
(Y*(8,L)C/T*8V)*B12 HD24 17 815 24.0 17.6 14.85 12.50
Y*9C*B12 HD24 17 790 24.0 17.6 14.60 12.30
(Y*(8,L)C/T*8V)*A12 HD36 14 805 23.4 16.8 14.30 12.10
(Y*(8,L)C/T*8V)*B12 HD36 17 760 23.4 16.5 14.35 12.10
(Y*(8,L)C/T*8V)*C16 HD36 21 855 23.8 17.4 14.70 12.35
(Y*(8,L)C/T*8V)*C20 HD36 21 750 23.4 16.4 14.75 12.40
Y*9C*B12 HD36 17 815 23.4 16.8 14.35 12.15
Y*9C*C16 HD36 21 785 23.6 16.8 14.60 12.35
Y*9C*C20 HD36 21 760 23.4 16.6 14.60 12.30
(Y*(8,L)C/T*8V)*A12 UC24A 14 805 23.6 17.4 14.55 12.10
(Y*(8,L)C/T*8V)*B12 UC24B 17 815 23.6 17.4 14.80 12.25
Y*9C*B12 UC24B 17 790 23.6 17.4 14.55 12.05
(Y*(8,L)C/T*8V)*A12 UC30A 14 805 23.6 17.4 14.55 12.10
(Y*(8,L)C/T*8V)*B12 UC30B 17 815 23.6 17.4 14.80 12.25
Y*9C*B12 UC30B 17 790 23.6 17.4 14.55 12.05
(Y*(8,L)C/T*8V)*A12 UC36A 14 805 22.8 16.7 14.05 11.85
(Y*(8,L)C/T*8V)*B12 UC36B 17 765 23.0 16.8 14.35 12.05
Y*9C*B12 UC36B 17 815 22.8 16.7 14.10 12.00
(Y*(8,L)C/T*8V)*C16 UC36C 21 855 23.2 17.4 14.40 12.10
(Y*(8,L)C/T*8V)*C20 UC36C 21 750 22.8 16.4 14.55 12.15
Y*9C*C16 UC36C 21 785 23.0 16.8 14.35 12.05
Y*9C*C20 UC36C 21 760 22.8 16.5 14.35 12.05
(Y*(8,L)C/T*8V)*C16 UC48C 21 815 23.4 17.3 14.65 12.25
Y*9C*C16 UC48C 21 880 23.6 17.9 14.40 12.15
TCHD30S41S3
T*(8,L)X*A12 FC/MC/PC30A 14 1065 28.2 21.1 14.05 12.50
T*(8,L)X*B12 FC/MC/PC30B 17 945 27.8 20.3 14.50 12.75
T*9X*B12 FC/MC/PC30B 17 1065 28.2 21.1 14.25 12.50
T*(8,L)X*A12 FC/MC/PC32A 14 970 28.0 20.7 13.65 12.25
T*(8,L)X*B12 FC/MC/PC35B 17 1090 28.4 21.6 14.50 12.75
T*(8,L)X*C16 FC/MC/PC35C 21 1090 28.4 21.6 14.75 13.00
T*(8,L)X*C20 FC/MC/PC35C 21 850 27.8 20.1 14.75 13.00
T*9X*B12 FC/MC/PC35B 17 1085 28.2 21.4 14.25 12.75
T*9X*C16 FC/MC/PC35C 21 1075 28.4 21.5 14.75 13.00
T*(8,L)X*A12 FC/MC/PC36A 14 995 28.2 20.7 14.00 12.25
T*(8,L)X*B12 FC/MC/PC36B 17 1075 28.4 21.5 14.50 12.50
T*(8,L)X*C16 FC/MC/PC36C 21 1090 28.4 21.2 14.75 13.00
T*(8,L)X*C20 FC/MC/PC36C 21 890 28.0 20.3 15.00 13.00
T*9X*B12 FC/MC/PC36B 17 1070 28.4 21.3 14.50 12.50
T*9X*C16 FC/MC/PC36C 21 1070 28.4 21.3 14.50 12.75
T*(8,L)X*A12 FC/MC/PC37A 14 1105 28.8 22.2 14.50 13.00
T*(8,L)X*B12 FC/MC/PC42B 17 1045 27.8 20.9 14.25 12.25
T*(8,L)X*C20 FC/MC/PC42C 21 920 27.0 19.9 14.50 12.50
T*9X*B12 FC/MC/PC42B 17 1045 27.8 20.9 14.25 12.25
T*9X*C16 FC/MC/PC42C 21 1035 27.6 20.3 14.25 12.25
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
