York TCHD18 - Page 12

556454-YTG-B-0410
12 Johnson Controls Unitary Products
TCHD30S41S3
T*(8,L)X*B12 FC/MC/PC43B 17 1115 28.8 21.6 14.25 12.25
T*(8,L)X*C20 FC/MC/PC43C 21 870 26.4 21.3 14.50 12.50
T*9X*B12 FC/MC/PC43B 17 1095 28.8 21.6 14.25 12.25
T*9X*C16 FC/MC/PC43C 21 1055 28.8 21.1 14.25 12.25
T*(8,L)X*C20 FC/MC/PC48C 21 890 28.8 20.9 15.50 13.50
T*9X*C16 FC/MC/PC48C 21 1075 29.4 22.6 15.25 13.25
T*(8,L)X*A12 HD36 14 1065 28.0 21.0 14.00 12.50
T*(8,L)X*B12 HD36 17 1065 28.0 21.0 14.00 12.50
T*(8,L)X*C16 HD36 21 1065 28.2 21.1 14.00 12.75
T*9X*B12 HD36 17 1065 28.0 21.0 14.00 12.50
T*(8,L)X*A12 UC30A 14 1065 28.2 21.3 14.00 12.50
T*(8,L)X*B12 UC30B 17 945 28.0 20.5 14.50 12.75
T*9X*B12 UC30B 17 1065 28.2 21.3 14.30 12.50
T*(8,L)X*A12 UC36A 14 995 26.8 19.5 13.50 11.75
T*(8,L)X*B12 UC36B 17 1065 28.2 21.3 14.50 12.50
T*(8,L)X*C16 UC36C 21 1075 28.4 21.3 14.75 12.75
T*(8,L)X*C20 UC36C 21 890 26.6 19.4 14.25 12.25
T*9X*B12 UC36B 17 1070 28.2 21.3 14.50 12.50
T*9X*C16 UC36C 21 1070 28.4 21.3 14.50 12.75
T*(8,L)X*B12 UC42B 17 1025 27.2 20.3 13.75 12.00
T*(8,L)X*C16 UC42C 21 825 26.0 18.2 14.25 12.25
T*(8,L)X*C20 UC42C 21 950 27.0 19.5 14.50 12.50
T*9X*B12 UC42B 17 1025 27.2 20.3 13.75 12.00
T*9X*C16 UC42C 21 1030 27.4 20.3 14.00 12.25
T*(8,L)X*C16 UC48C 21 815 26.4 18.9 14.50 12.50
T*(8,L)X*C20 UC48C 21 960 27.4 20.1 14.75 12.75
T*9X*C16 UC48C 21 1035 27.6 20.7 14.25 12.25
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 1055 28.2 21.4 14.05 12.40
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 955 28.2 21.0 15.00 13.15
Y*9C*B12 FC/MC/PC30B 17 1050 28.2 21.2 14.50 12.75
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 1045 28.0 21.0 13.65 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 995 28.4 21.2 14.50 13.00
Y*9C*B12 FC/MC/PC35B 17 1045 28.2 21.6 14.25 12.50
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 1025 28.4 21.4 15.00 13.15
(Y*(8,L)C/T*8V)*C20 FC/MC/PC35C 21 1080 28.8 22.2 15.05 13.20
Y*9C*C16 FC/MC/PC35C 21 1005 28.4 21.4 15.00 13.10
Y*9C*C20 FC/MC/PC35C 21 985 28.4 21.4 15.00 13.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 1000 28.2 21.0 14.50 12.75
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 985 28.4 21.0 14.80 13.05
Y*9C*B12 FC/MC/PC36B 17 985 28.4 21.0 14.70 13.00
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 1020 28.4 21.2 15.00 13.15
(Y*(8,L)C/T*8V)*C20 FC/MC/PC36C 21 1055 28.8 21.8 15.20 13.35
Y*9C*C16 FC/MC/PC36C 21 1005 28.4 21.2 15.00 13.20
Y*9C*C20 FC/MC/PC36C 21 1045 28.4 21.0 14.75 13.05
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 980 28.8 21.6 14.50 12.80
(Y*(8,L)C/T*8V)*B12 FC/MC/PC43B 17 990 28.8 21.8 15.00 13.20
Y*9C*B12 FC/MC/PC43B 17 1035 28.8 21.6 14.50 12.85
(Y*(8,L)C/T*8V)*C16 FC/MC/PC43C 21 990 29.0 21.8 15.35 13.60
(Y*(8,L)C/T*8V)*C20 FC/MC/PC43C 21 1000 29.0 21.8 15.40 13.65
Y*9C*C16 FC/MC/PC43C 21 1030 28.8 21.6 14.80 13.15
Y*9C*C20 FC/MC/PC43C 21 995 29.0 21.8 15.20 13.45
(Y*(8,L)C/T*8V)*A12 HC30 14 1030 27.6 20.6 13.50 12.00
(Y*(8,L)C/T*8V)*B12 HC36 17 995 28.4 21.2 14.50 13.00
Y*9C*B12 HC36 17 1045 28.2 21.6 14.30 12.50
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
