York TCHD18 - Page 13

556454-YTG-B-0410
Johnson Controls Unitary Products 13
TCHD30S41S3
(Y*(8,L)C/T*8V)*C16 HC42 21 990 29.0 21.8 15.35 13.60
(Y*(8,L)C/T*8V)*C20 HC42 21 1000 29.0 21.8 15.40 13.65
Y*9C*C16 HC42 21 1030 28.8 21.8 14.80 13.15
Y*9C*C20 HC42 21 995 29.0 21.8 15.20 13.45
(Y*(8,L)C/T*8V)*A12 HD36 14 1000 28.0 20.2 14.30 12.65
(Y*(8,L)C/T*8V)*B12 HD36 17 985 28.0 20.4 14.65 13.00
(Y*(8,L)C/T*8V)*C16 HD36 21 1020 28.2 20.4 14.80 13.05
(Y*(8,L)C/T*8V)*C20 HD36 21 1055 28.4 21.0 15.00 13.25
Y*9C*B12 HD36 17 985 28.0 20.4 14.60 12.85
Y*9C*C16 HD36 21 1005 28.2 20.4 14.85 13.05
Y*9C*C20 HD36 21 1045 28.0 20.4 14.65 13.00
(Y*(8,L)C/T*8V)*A12 UC30A 14 1055 28.2 21.6 14.00 12.40
(Y*(8,L)C/T*8V)*B12 UC30B 17 955 28.4 21.0 15.00 13.20
Y*9C*B12 UC30B 17 1000 28.2 20.8 14.30 12.70
(Y*(8,L)C/T*8V)*A12 UC36A 14 1000 28.2 20.8 14.30 12.70
(Y*(8,L)C/T*8V)*B12 UC36B 17 985 28.2 21.0 14.65 13.00
Y*9C*B12 UC36B 17 985 28.2 21.0 14.55 13.00
(Y*(8,L)C/T*8V)*C16 UC36C 21 1020 28.4 21.0 14.80 13.10
(Y*(8,L)C/T*8V)*C20 UC36C 21 1035 27.8 21.0 14.75 13.00
Y*9C*C16 UC36C 21 1000 28.4 21.0 14.80 13.10
Y*9C*C20 UC36C 21 1045 28.2 21.0 14.65 13.00
TCHD36S41S3
T*(8,L)X*A12 FC/MC/PC32A 14 1160 32.6 23.6 13.45 11.50
T*(8,L)X*B12 FC/MC/PC35B 17 1275 33.4 24.8 13.55 11.75
T*(8,L)X*C16 FC/MC/PC35C 21 1105 33.6 24.3 14.20 12.25
T*(8,L)X*C20 FC/MC/PC35C 21 1225 33.8 24.9 14.25 12.25
T*9X*B12 FC/MC/PC35B 17 1265 33.4 24.8 13.65 11.75
T*9X*C16 FC/MC/PC35C 21 1270 33.6 25.0 14.00 12.00
T*9X*C20 FC/MC/PC35C 21 1195 33.6 24.3 13.80 12.00
T*(8,L)X*A12 FC/MC/PC36A 14 1185 33.0 24.1 13.25 11.50
T*(8,L)X*B12 FC/MC/PC36B 17 1255 33.2 24.5 13.50 11.75
T*(8,L)X*C16 FC/MC/PC36C 21 1100 33.2 23.7 14.00 12.00
T*(8,L)X*C20 FC/MC/PC36C 21 1265 33.6 24.8 14.25 12.25
T*9X*B12 FC/MC/PC36B 17 1245 33.2 24.7 13.50 11.50
T*9X*C16 FC/MC/PC36C 21 1265 33.6 25.1 13.75 12.00
T*9X*C20 FC/MC/PC36C 21 1195 33.2 24.3 13.75 12.00
T*(8,L)X*A12 FC/MC/PC37A 14 1290 33.0 24.8 14.05 12.00
T*(8,L)X*B12 FC/MC/PC42B 17 1160 32.4 23.7 13.50 11.75
T*(8,L)X*C16 FC/MC/PC42C 21 1200 32.6 23.7 14.00 12.00
T*(8,L)X*C20 FC/MC/PC42C 21 1240 33.0 24.3 14.25 12.00
T*9X*B12 FC/MC/PC42B 17 1235 32.8 24.1 13.50 11.50
T*9X*C16 FC/MC/PC42C 21 1235 32.8 24.1 13.75 11.50
T*9X*C20 FC/MC/PC42C 21 1185 32.4 23.5 13.50 11.50
T*(8,L)X*B12 FC/MC/PC43B 17 1300 34.2 25.7 14.00 12.00
T*(8,L)X*C16 FC/MC/PC43C 21 1175 34.4 25.3 14.75 12.50
T*(8,L)X*C20 FC/MC/PC43C 21 1250 34.6 26.1 15.00 12.50
T*9X*B12 FC/MC/PC43B 17 1270 34.2 25.7 14.00 12.00
T*9X*C16 FC/MC/PC43C 21 1260 34.2 25.9 14.20 12.25
T*9X*C20 FC/MC/PC43C 21 1185 34.2 25.3 14.65 12.25
T*(8,L)X*C16 FC/MC/PC48C 21 1185 34.8 25.9 15.10 12.75
T*(8,L)X*C20 FC/MC/PC48C 21 1270 35.2 26.4 15.00 12.75
T*9X*C16 FC/MC/PC48C 21 1280 35.0 26.3 14.50 12.50
T*9X*C20 FC/MC/PC48C 21 1205 34.6 25.7 14.55 12.50
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
