COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(Min.-max.)
W
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
TCHD18S41S3
450 - 750 14,17 FC/MC/PC24 600 18.0 12.6 13.00 11.00
450 - 750 14,17 FC/MC/PC30 600 18.0 12.6 13.00 11.00
450 - 750 14 FC/MC/PC32 600 18.1 12.6 13.00 11.05
450 - 750 17 FC/MC/PC35 600 18.1 12.6 13.00 11.05
450 - 750 14,17 FC/MC/PC36 600 18.2 12.6 13.00 11.15
450 - 750 14 FC/MC/PC37 600 18.4 12.7 13.10 11.25
450 - 750 17 HC36 600 18.1 12.6 13.00 11.05
450 - 750 14,17 HD24 600 18.7 12.9 13.25 11.35
450 - 750 14,17 UC24 600 18.1 12.6 13.00 11.10
450 - 750 14,17 UC30 600 18.1 12.6 13.00 11.10
TCHD24S41S3
600 - 1000 14,17 FC/MC/PC24 800 23.0 16.8 13.00 11.00
600 - 1000 14,17 FC/MC/PC30 800 23.0 16.8 13.00 11.00
600 - 1000 14 FC/MC/PC32 800 23.0 16.9 13.15 11.00
600 - 1000 17,21 FC/MC/PC35 800 23.0 16.9 13.15 11.00
600 - 1000 14,17,21 FC/MC/PC36 800 23.0 16.9 13.15 11.00
600 - 1000 14 FC/MC/PC37 800 23.6 17.3 13.30 11.20
600 - 1000 17,21 FC/MC/PC43 800 23.6 17.3 13.30 11.20
600 - 1000 14 HC30 800 22.8 16.6 13.00 11.00
600 - 1000 17 HC36 800 23.0 16.9 13.15 11.00
600 - 1000 21 HC42 800 23.6 17.3 13.30 11.20
600 - 1000 14,17 UC24 800 23.0 16.9 13.05 11.00
600 - 1000 14,17 UC30 800 23.0 16.9 13.05 11.00
TCHD30S41S3
800 - 1200 14,17 FC/MC/PC30 1000 27.6 20.4 13.25 11.85
800 - 1200 14,17 FC/MC/PC32 1000 28.0 20.8 13.50 12.00
800 - 1200 17,21 FC/MC/PC35 1000 28.0 20.8 13.50 12.00
800 - 1200 14,17,21 FC/MC/PC36 1000 28.0 20.6 13.45 12.00
800 - 1200 14 FC/MC/PC37 1000 28.4 21.2 13.75 12.20
800 - 1200 17,21 FC/MC/PC43 1000 28.4 21.2 13.70 12.20
800 - 1200 14,17 HC30 1000 27.6 20.4 13.35 11.80
800 - 1200 17 HC36 1000 28.0 20.8 13.50 12.00
800 - 1200 21 HC42 1000 28.4 21.2 13.75 12.20
800 - 1200 14,17,21 HD36 1000 27.6 20.0 13.30 11.85
800 - 1200 14,17 UC30 1000 27.8 20.4 13.40 12.00
800 - 1200 21,24 UC48 1000 26.8 20.0 13.00 11.50
TCHD36S41S3
1000 - 1400 14 FC/MC/PC32 1200 33.2 24.2 13.20 11.50
1000 - 1400 17,21 FC/MC/PC35 1200 33.2 24.2 13.20 11.50
1000 - 1400 14,17,21 FC/MC/PC36 1200 33.0 24.0 13.00 11.40
1000 - 1400 14 FC/MC/PC37 1200 33.8 24.8 13.50 11.70
1000 - 1400 17,21 FC/MC/PC43 1200 34.0 24.8 13.50 11.75
1000 - 1400 21,24 FC/MC/PC48 1200 34.4 25.2 13.65 12.00
1000 - 1400 17 HC36 1200 33.2 24.2 13.20 11.50
1000 - 1400 21 HC42 1200 33.8 25.0 13.50 11.70
1000 - 1400 14,17,21 HD36 1200 32.4 23.2 13.00 11.20
1000 - 1400 14,17,21,24 HD48 1200 34.2 24.8 13.65 11.85
TCHD48S41S3
1400 - 1800 21,24 FC/MC/PC48 1600 47.0 33.8 13.25 11.50
1400 - 1800 21,24 FC/MC62 1600 47.5 34.2 13.35 11.60
1400 - 1800 14,17,21,24 HD48 1600 47.0 33.4 13.20 11.50
TCHD60S41S3 1600 - 2000 21,24 FC/MC62 1800 57.0 39.5 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
