York TCHD60 - Cooling Capacity - With High Efficiency Motor Furnaces; 13 SEER AC Cooling Capacity (Variable Speed Furnaces)

556454-YTG-B-0410
8 Johnson Controls Unitary Products
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
TCHD18S41S3
T*(8,L)X*A12 FC/MC/PC18A 14 540 17.7 12.4 14.00 11.50
T*(8,L)X*B12 FC/MC/PC18B 17 580 17.9 12.6 14.25 11.75
T*9X*B12 FC/MC/PC18B 17 590 17.9 12.8 14.25 11.75
T*(8,L)X*A12 FC/MC/PC24A 14 595 18.5 13.2 14.70 12.00
T*(8,L)X*B12 FC/MC/PC24B 17 620 18.4 13.1 14.75 12.00
T*9X*B12 FC/MC/PC24B 17 615 18.5 13.2 14.75 12.00
T*(8,L)X*A12 FC/MC/PC30A 14 595 18.5 13.2 14.70 12.00
T*(8,L)X*B12 FC/MC/PC30B 17 620 18.4 13.1 14.75 12.00
T*9X*B12 FC/MC/PC30B 17 615 18.5 13.2 14.75 12.00
T*(8,L)X*A12 FC/MC/PC32A 14 590 18.4 13.1 14.55 12.00
T*(8,L)X*A12 HD24 14 605 19.0 13.9 13.75 12.25
T*(8,L)X*B12 HD24 17 655 18.6 14.3 14.75 12.00
T*(8,L)X*C16 HD24 21 650 18.1 14.0 15.00 11.50
T*9X*B12 HD24 17 630 19.0 13.9 13.75 12.25
T*(8,L)X*A12 UC18A 14 590 18.1 12.8 14.50 11.75
T*(8,L)X*B12 UC18B 17 595 18.0 12.7 14.50 11.75
T*9X*B12 UC18B 17 590 18.1 12.8 14.50 11.75
T*(8,L)X*A12 UC24A 14 570 18.4 13.0 14.75 12.00
T*(8,L)X*B12 UC24B 17 575 18.4 13.0 14.75 12.00
T*9X*B12 UC24B 17 615 18.7 13.5 14.75 12.00
T*(8,L)X*A12 UC30A 14 570 18.4 13.0 14.75 12.00
T*(8,L)X*B12 UC30B 17 625 18.4 13.3 15.00 12.25
T*9X*B12 UC30B 17 615 18.7 13.5 14.75 12.00
(Y*(8,L)C/T*8V)*A12 FC/MC/PC18A 14 620 18.1 13.0 14.50 12.05
(Y*(8,L)C/T*8V)*B12 FC/MC/PC18B 17 580 17.9 12.7 14.50 12.05
Y*9C*B12 FC/MC/PC18B 17 610 18.1 13.0 14.60 12.20
(Y*(8,L)C/T*8V)*A12 FC/MC/PC24A 14 640 18.5 13.4 14.70 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC24B 17 575 18.4 13.0 15.00 12.40
Y*9C*B12 FC/MC/PC24B 17 610 18.5 13.4 14.85 12.30
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 640 18.5 13.4 14.70 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 575 18.4 13.0 15.00 12.40
Y*9C*B12 FC/MC/PC30B 17 610 18.5 13.4 14.85 12.30
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 590 18.4 13.1 14.55 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 650 18.6 13.4 14.70 12.30
Y*9C*B12 FC/MC/PC35B 17 570 18.4 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 600 18.6 13.4 15.05 12.55
Y*9C*C16 FC/MC/PC35C 21 645 18.6 13.4 14.85 12.40
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 645 18.7 13.4 14.80 12.35
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 650 18.7 13.5 15.00 12.45
Y*9C*B12 FC/MC/PC36B 17 635 18.7 13.5 15.00 12.45
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 595 18.8 13.5 15.20 12.65
Y*9C*C16 FC/MC/PC36C 21 595 18.8 13.5 15.20 12.65
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 625 18.7 13.5 14.80 12.35
(Y*(8,L)C/T*8V)*A12 HC18 14 620 18.1 13.0 14.50 12.05
(Y*(8,L)C/T*8V)*A12 HC30 14 590 18.2 12.8 14.50 12.05
(Y*(8,L)C/T*8V)*B12 HC36 17 650 18.7 13.6 14.75 12.40
Y*9C*B12 HC36 17 570 18.4 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*A12 HD24 14 640 19.1 13.8 15.10 12.60
(Y*(8,L)C/T*8V)*B12 HD24 17 575 19.0 13.4 15.30 12.75
Y*9C*B12 HD24 17 610 19.2 13.9 15.20 12.70
(Y*(8,L)C/T*8V)*A12 HD36 14 645 18.5 12.9 14.60 12.25
(Y*(8,L)C/T*8V)*B12 HD36 17 650 18.5 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*C16 HD36 21 595 18.6 12.9 15.00 12.50
For notes see Page 16.
