York THGD18 - Additional R-22 Charge; Orifice Size for Various Matched Systems

365147-YTG-C-0608
Johnson Controls Unitary Products 3
Additional R-22 Charge / Orifice Size for Various Matched Systems
Outdoor Unit
THGD18
S21S1
THGD24
S21S1
THGD30
S21S1
THGD36
S21S1
THGD42
S21S1
THGD48
S21S1
THGD60
S21S1
Required Orifice or TXV
1
1TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory Charge, lbs-oz 7 - 3 7 - 7 8 - 12 9 - 1 11 - 14 13 - 4 15 - 5
Indoor Coil
2,3
Additional Charge, Oz
FC/MC/PC/UC18A2A 0 ––––––
FC/MC/PC/UC18B2A 0 ––––––
FC/MC/PC/UC24A2A 0 0 –––––
FC/MC/PC/UC24B2A 0 0 –––––
FC/MC/PC/UC30A2A 0 0 –––––
FC/MC/PC/UC30B2A 0 0 –––––
FC/MC/PC/UC32A2A –5 0 ––––
FC/MC/PC/UC35B2A –5 0 ––––
FC/MC/PC/UC35C2A –5 0 ––––
FC/MC/PC/UC37A2A – – 0 0 – – –
FC/MC/PC/UC43C2C –––––––
FC/MC/PC/UC48C2C ––––0 ––
FC/MC/PC/UC48D2C ––––0 ––
FC/PC/UC60C2C ––––2 0 –
FC/MC/PC/UC60D2C ––––2 0 –
FC/PC62D2C –––––2 0
HC18A2A 0 ––––––
HC30A2A –0 –––––
HC36B2A –5 0 ––––
HC60C2C ––––2 0 –
HD24A2A –4 –––––
HD36B2A ––0 ––––
HD60D2C ––––2 0 –
MH30S2A –6 –––––
AHP18B2A 0 ––––––
AHP24B2A 0 0 –––––
AHP30B2A –5 0 ––––
AHP36C2A – – 0 0 – – –
AHP48D2C ––––2 0 –
AHP60D2C ––––2 0 –
AV24B2A 0 0 –––––
AV36C2A ––0 0 –––
AV48D2C ––––0 0 –
AV60D2C ––––0 0 –
FC/MC/PC/UC18A3X 2A + 0 ––––––
FC/MC/PC/UC18B3X 2A + 0 ––––––
FC/MC/PC/UC24A3X 2A + 0 2A + 0 –––––
FC/MC/PC/UC24B3X 2A + 0 2A + 0 –––––
FC/MC/PC/UC30A3X –2A + 0 –––––
FC/MC/PC/UC30B3X –2A + 0 –––––
FC/MC/PC/UC32A3X –2A + 5 2A + 0 ––––
FC/MC/PC/UC35B3X –2A + 5 2A + 0 ––––
FC/MC/PC/UC35C3X –2A + 5 2A + 0 ––––
FC/MC/PC/UC37A3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC43B3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC43C3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC48C3X – – – 2A + 3 2C + 0 – –
FC/MC/PC/UC48D3X – – – 2A + 3 2C + 0 – –
FC/PC/UC60C3X – – – 2A + 5 2C + 2 2C + 0 –
FC/MC/PC/UC60D3X – – – 2A + 5 2C + 2 2C + 0 –
FC/PC62D3X –––––2C + 2 2C + 0
For Notes See Page 4.
