York THGD18 - COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils

365147-YTG-C-0608
Johnson Controls Unitary Products 7
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(Min.-max.)
W
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
THGD18S21S1
450 - 750 14,17 FC/MC/PC/UC18 600 18.0 12.9 13.00 11.00
450 - 750 14,17 FC/MC/PC/UC24 600 18.0 12.9 13.00 11.00
450 - 750 14,17 FC/MC/PC/UC30 600 18.0 12.9 13.00 11.00
450 - 750 14 HC18 600 18.0 12.9 13.00 11.00
THGD24S21S1
600 - 1000 14,17 FC/MC/PC/UC24 800 23.0 16.8 13.00 11.00
600 - 1000 14,17 FC/MC/PC/UC30 800 23.0 16.8 13.00 11.00
600 - 1000 14 FC/MC/PC/UC32 800 23.0 16.8 13.00 11.00
600 - 1000 17,21 FC/MC/PC/UC35 800 23.0 16.8 13.00 11.00
600 - 1000 14 HC30 800 23.0 16.8 13.00 11.00
600 - 1000 17 HC36 800 23.0 16.8 13.00 11.00
600 - 1000 – HD24 800 23.0 16.8 13.00 11.00
600 - 1000 19 MH24S 800 23.0 16.8 13.00 11.00
600 - 1000 19 MH30S 800 23.0 16.8 13.00 11.00
THGD30S21S1
800 - 1200 14 FC/MC/PC/UC32 1000 29.0 21.2 13.00 11.00
800 - 1200 17,21 FC/MC/PC/UC35 1000 29.0 21.2 13.00 11.00
800 - 1200 14 FC/MC/PC/UC37 1000 29.0 21.2 13.00 11.00
800 - 1200 17,21 FC/MC/PC/UC43 1000 29.0 21.2 13.00 11.00
800 - 1200 17 HC36 1000 29.0 21.2 13.00 11.00
800 - 1200 21 HC42 1000 29.0 21.2 13.00 11.00
800 - 1200 – HD36 1000 29.0 21.2 13.00 11.00
800 - 1200 19 MH24S 1000 29.0 21.2 13.00 11.00
800 - 1200 19 MH30S 1000 29.0 21.2 13.00 11.00
THGD36S21S1
1000 - 1400 14 FC/MC/PC/UC37 1200 35.0 25.6 13.00 11.00
1000 - 1400 17,21 FC/MC/PC/UC43 1200 35.0 25.6 13.00 11.00
1000 - 1400 21,24 FC/MC/PC/UC48 1200 35.0 25.6 13.00 11.00
1000 - 1400 21,24 FC/MC/PC/UC60 1200 35.0 25.6 13.00 11.00
1000 - 1400 21 HC42 1200 35.0 25.6 13.00 11.00
1000 - 1400 24 HC60 1200 35.0 25.6 13.00 11.00
1000 - 1400 – HD48 1200 35.0 25.6 13.00 11.00
1000 - 1400 – HD60 1200 35.0 25.6 13.00 11.00
THGD42S21S1
1200 - 1600 21,24 FC/MC/PC/UC48 1400 40.0 28.8 13.00 11.00
1200 - 1600 21,24 FC/MC/PC/UC60 1400 40.0 28.8 13.00 11.00
1200 - 1600 24 HC60 1400 40.0 28.8 13.00 11.00
1200 - 1600 – HD60 1400 40.0 28.8 13.00 11.00
THGD48S21S1
1400 - 1800 21,24 FC/MC/PC/UC60 1600 45.0 33.2 13.00 11.00
1400 - 1800 24 FC/MC62 1600 45.0 33.2 13.00 11.00
1400 - 1800 24 HC60 1600 45.0 33.2 13.00 11.00
1400 - 1800 – HD60 1600 45.0 33.2 13.00 11.00
THGD60S21S1 1600 - 2000 24 FC/MC62 1800 55.0 40.0 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
