SECTION XII: START UP SHEET
33" 80% AFUE ECM Single Stage Ultra-Low NOx Gas Furnace Start Up Sheet
Proper furnace start up is critical to customer comfort and equipment longevity
Name Address
City State or Province Zip or Postal Code
Furnace Model Furnace Serial
Indoor Coil Model Indoor Coil Serial
Horizontal Left Horizontal Right
Unit is level
Filter Type
Polarity is correct (black is L1 (hot), white is N (neutral) Ground wire is connected
Line voltage value to furnace (volts AC)
Low voltage value between "R" and "C" on furnace control board (volts AC)
Thermostat Type
Other System Equipment and Accessories
Owner Information
Equipment Data
Furnace Configuration
Electrical: Line Voltage
Outdoor Unit Model Outdoor Unit Serial
Filter, Thermostat, Accessories
Filter Location(s)
Connections -- All Per Installation Instructions and Local Code
Gas piping is connected (including drip leg) Supply plenum and return air are connected
Filter Size
Vent system is connected
Thermostat wiring is complete Thermostat heat anticipator set to .40 (if present)
Electrical: Low Voltage
Technician Performing Start-Up Installing Contractor Name
Start-Up Date
Continued on next Page
Venting: B Vent
Connector Length
# of 45 Degree Ells
# of 90 Degree Ells
Connector Size
Vent Pipe Size
Vertical Termination
Total Height
# of 45 Degree Ells
# of 90 Degree Ells
Vent Pipe Size
Horizontal Term. (with External Power Vent)
Water Heater BTUH Input Fan Assisted?
Venting system is the proper size, within the limitations of the chart in the
installation instructions, properly connected to the furnace, and properly pitched
Connector Size
Connector Length
# of 45 Degree Ells
# of 90 Degree Ells
B Vent Connector
Venting: Lined Masonry Chimney
Other appliances in same common vent:
Furnace BTUH Input Fan Assisted?
Other BTUH Input Fan Assisted?
Chimney Height
Y N
N
Y
Y N
Single Wall Connector
