York XP048 - XP036-060 Physical Data Continued

251933-YTG-J-1009
Johnson Controls Unitary Products 17
CONDENSER FAN DATA
Quantity 1 1 1
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Drive Direct Drive Direct Drive
No. speeds 1 1 1
Number of motors 1 1 1
Motor HP each 1/4 1/2 1/2
RPM 850 1090 1090
Nominal total CFM 3275 4200 4200
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 12 x 10 12 x 10 12 x 10
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL44 1VP56 1VL44 1VP56 1VL44 1VP56
Blower Sheave AK64 AK66 AK56 AK61 AK56 AK56
Belt A37 A39 A36 A38 A36 A38
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725
Frame size 56 56 56
DIRECT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 12 x 10 12 x 10 12 x 10
Type Centrifugal Centrifugal Centrifugal
Motor HP each 3/4 1 1
RPM 1050 1050 1050
FILTERS
15” x 20” x 1” or 2” 2 2 2
14” x 25” x 1” or 2” 1 1 1
XP036-060 Physical Data (Continued)
Component
Models
XP036 XP048 XP060
Nominal Tonnage 3.0 4.0 5.0
