251933-YTG-J-1009
Johnson Controls Unitary Products 37
XP036-060 Cooling Capacities
XP036 (3.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
750
77 43.4 2.1 20.2 17.0 13.8 - - - 41.3 2.4 18.4 15.3 12.2 - - -
72 40.8 2.1 25.0 21.8 18.6 15.4 - - 38.5 2.4 23.2 20.2 17.1 14.0 - -
67 38.2 2.1 29.9 26.7 23.5 20.3 17.1 - 35.6 2.4 28.1 25.0 21.9 18.9 15.8 -
62 32.1 2.1 32.1 34.4 29.0 25.8 22.6 19.4 32.0 2.4 32.0 32.0 27.1 24.1 21.0 17.9
900
77 45.5 2.1 22.4 18.7 15.0 - - - 42.9 2.4 20.6 17.0 13.3 - - -
72 42.8 2.1 27.7 24.0 20.2 16.5 - - 40.0 2.4 25.9 22.3 18.6 15.0 - -
67 40.0 2.1 32.9 29.2 25.5 21.7 18.0 - 37.0 2.4 31.2 27.6 24.0 20.3 16.7 -
62 33.7 2.1 33.7 35.2 31.5 27.7 24.0 20.2 33.3 2.4 33.3 33.3 29.6 26.0 22.4 18.8
57 31.0 2.1 31.0 31.0 29.4 25.6 21.9 18.1 31.2 2.4 31.2 31.2 28.7 25.1 21.5 17.9
1050
77 47.6 2.1 24.7 20.4 16.1 - - - 44.5 2.4 22.8 18.6 14.5 - - -
72 44.7 2.1 30.4 26.1 21.8 17.5 - - 41.5 2.4 28.5 24.4 20.2 16.1 - -
67 41.9 2.1 36.0 31.7 27.5 23.2 18.9 - 38.4 2.4 34.3 30.1 26.0 21.8 17.7 -
62 35.3 2.1 35.3 36.0 33.9 29.6 25.3 21.1 34.5 2.4 34.5 34.5 32.1 28.0 23.8 19.7
57 32.5 2.1 32.5 32.5 31.6 27.4 23.1 18.8 32.4 2.4 32.4 32.4 31.1 27.0 22.8 18.7
1200
77 49.6 2.1 27.0 22.1 17.3 - - - 46.1 2.4 25.0 20.3 15.6 - - -
72 46.7 2.1 33.0 28.2 23.4 18.6 - - 43.0 2.4 31.1 26.5 21.8 17.1 - -
67 43.7 2.1 39.1 34.3 29.4 24.6 19.8 - 39.8 2.4 37.3 32.7 28.0 23.3 18.6 -
62 36.8 2.1 36.8 36.8 36.4 31.6 26.7 21.9 35.8 2.4 35.8 35.8 34.6 29.9 25.3 20.6
57 33.9 2.1 33.9 33.9 33.9 29.1 24.3 19.5 33.5 2.4 33.5 33.5 33.5 28.9 24.2 19.5
1350
72 46.9 2.1 35.4 30.1 24.8 19.5 - - 43.3 2.4 33.4 28.3 23.2 18.0 - -
67 43.9 2.1 41.6 36.6 31.3 26.0 20.7 - 40.1 2.4 38.8 34.9 29.8 24.6 19.5 -
62 37.0 2.1 37.0 37.0 36.8 31.5 26.2 20.9 36.0 2.4 36.0 36.0 35.4 30.3 25.2 20.0
57 34.1 2.1 34.1 34.1 34.1 28.8 23.5 18.2 33.8 2.4 33.8 33.8 33.8 28.6 23.5 18.4
1500
72 47.1 2.1 37.8 32.0 26.3 20.5 - - 43.6 2.4 35.7 30.2 24.6 19.0 - -
67 44.1 2.1 44.1 38.8 33.1 27.3 21.5 - 40.3 2.4 40.3 37.1 31.6 26.0 20.4 -
62 37.1 2.1 37.1 37.1 37.1 31.4 25.6 19.8 36.3 2.4 36.3 36.3 36.3 30.7 25.1 19.5
57 34.2 2.1 34.2 34.2 34.2 28.4 22.7 16.9 34.0 2.4 34.0 34.0 34.0 28.4 22.8 17.2
95°F 105°F
750
77 39.2 2.8 16.5 13.6 10.7 - - - 35.6 3.1 14.8 12.4 9.5 - - -
72 36.1 2.7 21.4 18.5 15.5 12.6 - - 32.9 3.1 20.2 17.2 14.3 11.4 - -
67 33.0 2.7 26.3 23.3 20.4 17.5 14.5 - 30.2 3.1 25.5 22.1 19.1 16.2 13.3 -
62 31.9 2.6 31.9 29.6 25.3 22.4 19.4 16.5 28.4 3.0 28.4 27.3 23.2 20.3 17.3 14.4
900
77 40.3 2.8 18.7 15.2 11.7 - - - 36.8 3.1 17.4 13.9 10.5 - - -
72 37.2 2.7 24.0 20.6 17.1 13.6 - - 34.0 3.1 22.7 19.3 15.8 12.3 - -
67 34.0 2.7 29.4 25.9 22.4 19.0 15.5 - 31.2 3.1 28.1 24.6 21.1 17.7 14.2 -
62 32.9 2.6 32.9 31.3 27.8 24.4 20.9 17.4 29.4 3.0 29.4 28.6 25.6 22.2 18.7 15.2
57 31.4 2.6 31.4 31.4 28.1 24.6 21.1 17.6 28.7 3.1 28.7 28.7 25.7 22.3 18.8 15.4
1050
77 41.5 2.8 20.8 16.8 12.8 - - - 38.0 3.1 19.9 15.4 11.5 - - -
72 38.2 2.7 26.7 22.6 18.6 14.6 - - 35.1 3.1 25.3 21.3 17.3 13.3 - -
67 35.0 2.7 32.5 28.5 24.5 20.5 16.5 - 32.3 3.1 30.6 27.1 23.2 19.2 15.2 -
62 33.8 2.6 33.8 33.0 30.4 26.4 22.3 18.3 30.4 3.0 30.4 30.0 28.0 24.1 20.1 16.1
57 32.3 2.7 32.3 32.3 30.6 26.6 22.6 18.6 29.7 3.1 29.7 29.7 28.2 24.2 20.2 16.2
1200
77 42.6 2.8 22.9 18.4 13.9 - - - 39.3 3.1 22.5 17.0 12.4 - - -
72 39.3 2.7 29.3 24.7 20.2 15.6 - - 36.3 3.1 27.8 23.3 18.8 14.3 - -
67 35.9 2.7 35.6 31.1 26.5 22.0 17.4 - 33.3 3.0 33.2 29.7 25.2 20.6 16.1 -
62 34.7 2.6 34.7 34.7 32.9 28.3 23.8 19.3 31.4 3.0 31.4 31.4 30.5 26.0 21.4 16.9
57 33.2 2.7 33.2 33.2 33.2 28.6 24.1 19.5 30.6 3.1 30.6 30.6 30.6 26.1 21.6 17.1
1350
72 39.7 2.8 31.5 26.5 21.5 16.6 - - 36.3 3.1 30.0 25.0 20.1 15.1 - -
67 36.3 2.7 36.1 33.3 28.3 23.3 18.3 - 33.4 3.1 33.3 31.2 26.9 21.9 17.0 -
62 35.1 2.7 35.1 35.1 34.1 29.2 24.2 19.2 31.4 3.0 31.4 31.4 31.0 26.0 21.1 16.1
57 33.5 2.7 33.5 33.5 33.5 28.5 23.5 18.5 30.7 3.1 30.7 30.7 30.7 25.7 20.7 15.8
1500
72 40.0 2.8 33.7 28.3 22.9 17.5 - - 36.4 3.1 32.2 26.8 21.4 16.0 - -
67 36.6 2.7 36.6 35.4 30.0 24.6 19.2 - 33.4 3.1 33.4 32.8 28.6 23.2 17.8 -
62 35.4 2.7 35.4 35.4 35.4 30.0 24.6 19.2 31.5 3.0 31.5 31.5 31.5 26.1 20.7 15.3
57 33.8 2.7 33.8 33.8 33.8 28.4 23.0 17.6 30.7 3.1 30.7 30.7 30.7 25.3 19.9 14.5
