York XP048 - XP036-060 Electrical Data (Belt Drive)

251933-YTG-J-1009
70 Johnson Controls Unitary Products
XP036-060 (Belt Drive)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
036
(3.0)
208-1-60 16.6 88.0 26.0 1.6 7.6 0.0
None - - - 30.0 40
E05 4.0 1 19.2 54.0 60
E07 5.6 1 26.9 63.6 70
E10 8.0 1 38.5 78.0 80
E15 11.9 2 57.2 101.5 110
E20 15.9 2 76.4 125.5 150
230-1-60 16.6 88.0 26.0 1.6 7.6 0.0
None - - - 30.0 40
E05 5.3 1 23.0 57.6 60
E07 7.5 1 32.6 69.0 70
E10 10.6 1 46.1 85.2 90
E15 15.9 2 69.1 112.8 125
E20 21.2 2 92.2 140.4 150
208-3-60 12.8 95.0 20.0 1.6 5.2 0.0
None - - - 22.8 30
E05 4.0 1 11.1 36.7 45
E07 5.6 1 15.5 42.2 50
E10 8.0 1 22.2 50.6 60
E15 11.9 2 33.0 64.1 70
E20 15.9 2 44.1 78.0 80
230-3-60 12.8 95.0 20.0 1.6 5.2 0.0
None - - - 22.8 30
E05 5.3 1 13.3 38.7 45
E07 7.5 1 18.8 45.4 50
E10 10.6 1 26.6 54.7 60
E15 15.9 2 39.9 70.6 80
E20 21.2 2 53.2 86.5 90
460-3-60 6.4 45.0 10.0 0.8 2.6 0.0
None - - - 11.4 15
E07 6.8 1 8.5 21.6 25
E10 10.1 1 12.7 26.6 30
E15 13.6 2 17.1 31.8 35
E20 19.5 2 24.5 40.7 45
575-3-60 5.4 38.0 8.5 0.6 2.0 0.0
None - - - 9.2 15
E10 10.6 1 10.6 22.0 25
E15 15.9 1 16.0 28.4 30
E20 21.2 2 21.3 34.7 35
048
(4.0)
208-1-60 21.1 113.0 33.0 2.3 7.6 0.0
None - - - 36.3 45
E05 4.0 1 19.2 60.3 70
E07 5.6 1 26.9 69.9 80
E10 8.0 1 38.5 84.4 90
E15 11.9 2 57.2 107.8 110
E20 15.9 2 76.4 131.8 150
230-1-60 21.1 113.0 33.0 2.3 7.6 0.0
None - - - 36.3 45
E05 5.3 1 23.0 63.9 70
E07 7.5 1 32.6 75.3 80
E10 10.6 1 46.1 91.5 100
E15 15.9 2 69.1 119.1 125
E20 21.2 2 92.2 146.7 150
208-3-60 16.0 120.0 25.0 2.3 5.2 0.0
None - - - 27.5 35
E05 4.0 1 11.1 41.4 50
E07 5.6 1 15.5 46.9 50
E10 8.0 1 22.2 55.3 60
E15 11.9 2 33.0 68.8 70
E20 15.9 2 44.1 82.7 90
230-3-60 16.0 120.0 25.0 2.3 5.2 0.0
None - - - 27.5 35
E05 5.3 1 13.3 43.4 50
E07 7.5 1 18.8 50.1 60
E10 10.6 1 26.6 59.4 60
E15 15.9 2 39.9 75.3 80
E20 21.2 2 53.2 91.2 100
460-3-60 8.3 60.0 13.0 1.3 2.6 0.0
None - - - 14.3 20
E07 6.8 1 8.5 24.5 30
E10 10.1 1 12.7 29.5 30
E15 13.6 2 17.1 34.7 35
E20 19.5 2 24.5 43.6 45
575-3-60 6.7 40.0 10.5 1.3 2.0 0.0
None - - - 11.4 15
E10 10.6 1 10.6 24.2 25
E15 15.9 1 16.0 30.5 35
E20 21.2 2 21.3 36.9 40
