York YHVP User Manual

YHVP/YHVP-ECM
Fan Coil
Johnson Controls take part to the Eurovent program of fan coil performance certication.
The official gures are published in the Eurovent web sites www.eurovent-certication.com and
www.certiash.com.
The tested performances are:
• Cooling total emission at the following conditions:
- water temperature +7°C E.W.T. +12°C L.W.T.
- air temperature +27°C dry bulb +19°C wet bulb
•
Cooling sensible emission at the following conditions:
- water temperature +7°C E.W.T. +12°C L.W.T.
- air temperature +27°C dry bulb +19°C wet bulb
• Heating emission (2-pipe units) at the following conditions:
- water temperature +50°C E.W.T.
- air temperature +20°C
-
water ow rate as for the cooling conditions
• Fan absorption • Water pressure drop • Sound power
INTRODUCTION
YHVP is the high wall fan coil unit designed and manufactured in
Europe, in 4 sizes and many different models.
YHVP is easy to install like a standard fan coil: without decreasing
the emission and without any extra frame, 2 way or 3 way valves
and condensate pump can be mounted into the casing.
The modern and appealing design of the unit in RAL 9003 colour
allows the use of
YHVP in any environment.
YHVP is available with standard AC motors or low energy EC
motors and in the following versions: with wired wall control,
infra-red remote control, MB electronic board for Modbus
management and electric heating coil.
The units are for 2 pipe installations only.
All the
YHVP models perform very low electric consumption and
extremely quite sound levels according to the request of today’s
new projects.
CONTENTS
YHVP Serie
• Versions and Main Components Page 3
• Dimensions, Weight, Water content Page 4
• EUROVENT certications Page 6
• Working conditions Page 7
• Emissions Page 8
• Water side pressure drop Page 10
• Accessories Page 10
• Control operations Page 11
• Wall electronic controls Page 12
• Electronic control accessories Page 15
• Controls and units Page 16
YHVP-ECM Serie
• Versions and Main Components Page 17
• Dimensions, Weight, Water content Page 18
• EUROVENT certications Page 20
• Working conditions Page 21
• Emissions Page 22
• Models with electric heater Page 24
• Water side pressure drop Page 25
• Accessories Page 25
• ECM conguration Page 26
• Controls and units
T and MB versions Page 27
YHVP / YHVP-ECM Serie
• Controls and units
T version Page 28
• Controls and units
MB version Page 29
• Management system for a network of units Page 34
• Accessories Page 37

York YHVP Specifications

General

Refrigerant	R-410A
Type	Heat Pump
Cooling Capacity	9, 000 - 36, 000 BTU/h
Operating Temperature (Heating)	-15°C to 24°C
Power Supply	208/230V, 1-phase, 60Hz
