Table 7: Display only fields
Field/LED name Description
Condenser Pressure Displays the refrigerant pressure in the condenser.
Condenser Saturation
Temperature
Displays the saturation temperature in the condenser.
Oil Sump Temperature Displays the temperature of the oil in the sump.
Oil Pressure
Displays the pressure differential between the high side oil
pressure transducer (output of oil filter) and the low side oil
pressure transducer (compressor housing). The displayed value
includes offset pressure derived from auto-zeroing during the
System Prelube. If either of the transducers used to calculate this
differential is out of range, the display field will show XX.X.
Table 8: Programmable
Button Access level Description
None – –
Table 9: Navigation
Button Access level Description
Home View Returns user to HOME Screen.
Economizer
System
View
Navigates to a screen displaying the Economizer System
parameters.
27YK-EP Style B Centrifugal Chiller
