York YLAA0120 Installation Operation & Maintenance

JOHNSON CONTROLS
43
FORM 150.72-ICOM6
ISSUE DATE: 12/29/2017
55
OPERATIONAL LIMITATIONS (ENGLISH)
TABLE 3 - TEMPERATURES AND FLOWS
UNIT
DESIGNATION
TEMPERATURE
WATER FLOW
(GPM) MIN
WATER FLOW
(GPM) MAX
AIR ON CONDENSER (°F)
MIN
1
MAX
2
MIN
3
MAX
4
STANDARD EFFICIENCY
YLAA0070SE 40 55 60 325 0 125
YLAA0080SE 40 55 100 350 0 125
YLAA0089SE 40 55 100 400 0 125
YLAA0100SE 40 55 100 400 0 125
YLAA0120SE 40 55 150 625 0 125
YLAA0136SE 40 55 115 530 0 125
YLAA0155SE 40 55 150 625 0 125
YLAA0170SE 40 55 138 525 0 125
HIGH EFFICIENCY
YLAA0058HE 40 55 60 325 0 125
YLAA0065HE 40 55 60 325 0 125
YLAA0081HE 40 55 115 530 0 125
YLAA0092HE 40 55 100 400 0 125
YLAA0101HE 40 55 100 400 0 125
YLAA0125HE 40 55 100 400 0 125
YLAA0142HE 40 55 150 530 0 125
YLAA0156HE 40 55 138 525 0 125
YLAA0175HE 40 55 200 650 0 125
YLAA0200HE 40 55 230 625 0 125
YLAA0230HE 40 55 220 625 0 125
NOTES:
1. For leaving liquid temperature below 40°F (4°C) (to 10°F [-12°C]) optional low temperature glycol kit required. Contact your
nearest Johnson Controls Ofce for application requirements.
2. For leaving liquid temperature higher than 55°F (13°C), contact the nearest Johnson Controls Ofce for application guidelines.
3. The evaporator is protected against freezing to -20°F (-29°C) with an electric heater as standard.
4. For operation at temperatures above 115°F (46°C), the optional High Ambient Kit will need to be installed on the system.
Excessive ow will cause damage to the
cooler. Do not exceed maximum cooler
ow. Special care should be taken when
multiple chillers are fed by a single pump.
SECTION 5 – TECHNICAL DATA

York YLAA0120 Specifications

General

Brand	York
Model	YLAA0120
Category	Chiller
Language	English
