York YUFE60BYSM-MS-1 - Page 46

Maintenance and
Disassembly
 Page 42 
2. Fan motor and fan
Procedure Illustration
1) Remove 10 screws of the top cover
and then remove the top cover. (see
CJ_A6_006)
2) Release the 8 hooks of volute shell.
(see CJ_A6_007)
CJ_A6_006
CJ_A6_007
Note: This section is for reference only. Actual unit appearance may vary.
