Unit Weights & Dimensions (Continued)
5
Heat Exchanger
Size
A - Height
B - Width
C - Length
6
D - Tube
Removal
Clearance
Maximum
Shipping Weight
7
FB2910/CA2110
2.3 m (7.4’)
1.8 m (5.9’)
3.1 m (10’)
3.1 m (10’)
5950 kg (13100 lb)
FB2912/SA2512
2.4 m (7.9’)
1.9 m (6.2’)
3.7 m (12’)
3.7 m (12’)
7650 kg (16850 lb)
FA3312/SA2512
2.5 m (8.2’)
2.1 m (6.9’)
3.7 m (12’)
3.7 m (12’)
8600 kg (18300 lb)
FA3312/CA2512
2.6 m (8.5’)
2.1 m (6.9’)
3.7 m (12’)
3.7 m (12’)
8850 kg (19500 lb)
FA3314/SA3314
2.8 m (9.2’)
2.3 m (7.5’)
4.3 m (14’)
4.3 m (14’)
10900 kg (24000 lb)
FA3914/SA3314
2.9 m (9.4’)
2.4 m (7.9’)
4.3 m (14’)
4.3 m (14’)
11750kg (25900 lb)
FA3914/CA3314
3.1 m (10.0’)
2.4 m (7.9’)
4.3 m (14’)
4.3 m (14’)
12800 kg (28200 lb)
FA3916/SA3916
3.3 m (10.7’)
2.6 m (8.5’)
4.9 m (16’)
4.9 m (16’)
16050 kg (35350 lb)
FB4816/SA3916
3.4 m (11.2’)
2.9 m (9.3’)
4.9 m (16’)
4.9 m (16’)
18250 kg (40250 lb)
FB4816/CA3916
3.5 m (11.4’)
2.9 m (9.3’)
4.9 m (16’)
4.9 m (16’)
20100 kg (44350 lb)
FB4818/SA4418
3.9 m (12.5’)
3.1 m (10.0’)
5.5 m (18’)
5.5 m (18’)
23000 kg (50700 lb)
FB5618/SA4418
4.0 m (13.0’)
3.4 m (10.9’)
5.5 m (18’)
5.5 m (18’)
25450 kg (56100 lb)
5
Actual weights and dimensions for specific configurations can be provided by your local sales representative
6
Length (C) does not include length of waterboxes
7
Shipping Weight does not include refrigerant, which varies based on design condition
