York ZE072 - E05; E15 E20 E30; E20; E30

5742637-YIM-D-0620
24 Johnson Controls Ducted Systems
060
(5.0)
208-1-60
4
24.4 144.2 38 4.4 6.7 10
NONE - - - 51.6 70
E05 4 1 19.2 51.6 70
E07 5.6 1 26.9 54.5 70
E10 8 1 38.5 69 70
E15 11.9 2 57.2 92.4 100
E20 15.9 2 76.4 116.4 125
E30 22.2 2 106.7 154.3 175
230-1-60
4
24.4 144.2 38 4.4 6.7 10
NONE - - - 51.6 70
E05 5.3 1 22.1 51.6 70
E07 7.5 1 31.2 59.9 70
E10 10.6 1 44.2 76.1 80
E15 15.9 2 66.2 103.7 110
E20 21.2 2 88.3 131.3 150
E30 29.6 2 123.3 175 200
208-3-60 16 110 24.9 4.4 4.3 10
NONE - - - 38.7 50
E05 4 1 11.1 38.7 50
E07 5.6 1 15.5 38.7 50
E10 8 1 22.2 45.6 50
E15 11.9 2 33 59.2 60
E20 15.9 2 44.1 73 80
E30 22.2 2 61.6 94.9 100
230-3-60 16 110 24.9 4.4 4.3 10
NONE - - - 38.7 50
E05 5.3 1 12.7 38.7 50
E07 7.5 1 18 40.4 50
E10 10.6 1 25.5 49.7 50
E15 15.9 2 38.2 65.7 70
E20 21.2 2 51 81.6 90
E30 29.6 2 71.2 106.9 110
460-3-60 7.8 52 12.1 4.4 2.1 5
NONE - - - 19 25
E07 6.8 1 8.2 19.1 25
E10 10.1 1 12.1 24.1 25
E15 13.6 2 16.4 29.3 30
E20 19.5 2 23.5 38.2 40
E30 28.8 2 34.6 52.2 60
575-3-60 5.7 38.9 8.9 4.4 1.9 4
NONE - - - 14.8 15
E10 10.6 1 10.2 20.1 25
E15 15.9 2 15.3 26.5 30
E20 21.2 2 20.4 32.9 35
E30 30.4 2 29.3 43.9 45
072
(6)
208-3-60 19.6 136 27 4.4 4.3 20
None - - - 43.2 60
E05 4 1 11.1 43.2 60
E07 5.6 1 15.5 43.2 60
E10 8 1 22.2 45.6 60
E15 11.9 1 33 59.1 60
E20 15.9 2 44.1 73 80
E30 22.2 2 61.6 94.9 100
230-3-60 19.6 136 27 4.4 4.3 20
None - - - 43.2 60
E05 5.3 1 12.7 43.2 60
E07 7.5 1 18 43.2 60
E10 10.6 1 25.5 49.8 60
E15 15.9 1 38.2 65.6 70
E20 21.2 2 51 81.6 90
E30 29.6 2 71.2 106.9 110
460-3-60 9.4 66.1 13 2.4 2.1 20
None - - - 21.3 30
E07 6.8 1 8.2 21.3 30
E10 10.1 1 12.1 24 30
E15 13.6 1 16.4 29.4 30
E20 19.5 2 23.5 38.3 40
E30 28.8 2 34.6 52.1 60
575-3-60 7.1 55.3 10 4.4 1.9 20
None - - - 16.6 20
E10 10.6 1 10.2 20.1 25
E15 15.9 1 15.3 26.5 30
E20 21.2 2 20.4 32.9 35
E30 30.4 2 29.3 44 45
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
4. Electrical data for single phase gas heating units with belt drive is at the end of the electrical data section.
ZE036-072 - With Powered Convenience Outlet (Belt Drive) (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Accessory
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
