YOSUDA H-185 User Manual

13
PARTS LIST
No. Description Qty. No. Description Qty.
1
Main frame
1
36
Bearing 608
4
2
Front stabilizer
1
37
Bearing 6000
10
3
Rear stabilizer
1
38
Flywheel 3KG
1
4
Slide rail
1
39
Shaft sleeve
1
5
Magnet assembly
1
40
Magnetic control shaft
1
6
Hex screw M10*105
1
41
Magnet
7
7
Hexagon socket screw M8*20
4
42
Induction magnet
1
8
Buffer shaft
2
43
Roller
2
9
Spring washers 10
3
44
Handlebar
1
10
Self-tapping screw 4.2*16
8
45
Cylindrical cushion
4
11
Hexagon socket round head bolt M8*16
4
46
Cushion roller
3
12
Hexagon socket half round head screw
M8*40
2
47
Inclined tube plug
1
13
Hexagon socket half round head screw
M6*50
1
48
Back pipe plug
1
14
Hexagon socket half round head screw
M8*125
3
49
Knob M16
1
15
Hexagon socket half round head screw
M12*150
4
50
Belt wheel
1
16
Hexagon socket half round head screw
M8*45
1
51
Belt roller
1
17
Jack M6*35
2
52
Adjuster
1
18
Nuts M6
5
53
Monitor
1
19
Nuts M8
3
54
Exit cover
1
20
Hexagonal nut M10
4
55
Square pipe
1
21
Hexagonal nut M10*1.25
2
56
Left/Right pedals
1
22
Cover type union nut M10
1
57
Mobile Phone holder
1
23
Flange nut M8
2
58
Decorative cover
1
24
Flange nut M10*1.25
4
59
Left/Right chain cover
1
25
Flat washer 8*19
11
60
Seat
1
26
Flat washer 6*22
1
61
Semicircle pipe
4
27
Flat washer 6*12
4
62
Foot tube adjuster
4
28
Spring washers 8
11
63
handlebar pipe plug
2
29
Flat washer 10*20
3
64
Belt
1
30
Circlip 10
3
65
Pad
2
31
Circlip 8
2
66
Hardware kit
1
32
Metallurgy ring
6
67
Multi-function wrench
1
33
Single head bolt
1
68
Inner hexagon wrench 6
1
34
Sensor wire
1
69
Hexagon inside half
roundM12*20
2
35
Connection piece
2
70
Cross round head tapping screw
8*18
5

YOSUDA H-185 Specifications

General

Brand	YOSUDA
Model	H-185
Category	Home Gym
Language	English
