4.Installation
A. Clip Installation
※ Install the clip according to a user socket as shown in the image.
- install the clip that fits the socket using the clip bolt
Make sure the Clips are bent downwards when mounted on top of the CPU.
Intel Clip AMD Clip
Caution
Intel Socket Clip Installation
AMD Socket Clip Installation
